1771-WA 現場接線臂，通常也被稱為接線底座或端子塊，是工業自動化控制系統中用于連接PLC（可編程邏輯控制器）與外部設備或傳感器的硬件設備。這些設備在控制系統中起著至關重要的作用，因為它們提供了從PLC到實際物理設備的電氣接口。
現場接線臂通常具有多個接線端子，這些端子允許用戶將電纜或?qū)Ь€連接到PLC的輸入/輸出（I/O）模塊。通過正確的接線，PLC可以讀取來自傳感器的信號，并控制執行器、電機等設備的操作。
現場接線臂的設計通?？紤]到了易用性、可靠性和安全性。它們可能具有標記或指示器，以幫助用戶正確連接導線，并可能包含保護機制，如短路保護或過載保護，以防止?jié)撛诘碾姎夤收稀?br /> 在使用現場接線臂時，需要遵循制造商的安裝指南和最佳實踐，以確保連接的準確性和系統的穩定性。不正確的接線可能導致信號干擾、系統故障或甚至設備損壞。
總的來說，現場接線臂是工業自動化控制系統中不可或缺的一部分，它們確保了PLC與外部設備之間的電氣連接，從而實現了對整個系統的有效控制。

1771-WA

The 1771-WA field wiring arm, also commonly referred to as a wiring base or terminal block, is a hardware device used in industrial automation control systems to connect a PLC (programmable logic controller) to an external device or sensor. These devices play a vital role in the control system as they provide the electrical interface from the PLC to the actual physical device.
The field boom typically has multiple terminals that allow the user to connect a cable or wire to the input/output (I/O) module of the PLC. With the correct wiring, the PLC can read the signal from the sensor and control the operation of the actuator, motor and other equipment.
Field connection arms are often designed with ease of use, reliability, and safety in mind. They may have markers or indicators to help users connect wires correctly and may contain protective mechanisms such as short-circuit protection or overload protection to prevent potential electrical failures.
When using the field boom, the manufacturer’s installation guidelines and best practices need to be followed to ensure the accuracy of the connection and the stability of the system. Incorrect wiring can result in signal interference, system failure, or even equipment damage.
In general, the field wiring arm is an integral part of the industrial automation control system, they ensure the electrical connection between the PLC and the external equipment, thus achieving effective control of the entire system.
