2711-K6C15

彩色編碼設計和動畫創建詳細的過程模擬

Allen-Bradley 2711-K10C1是PanelView標準操作員終端。它具體屬于子類別PanelView 1000，具有10英寸，彩色有源矩陣TFT屏幕，鍵盤用戶界面和遠程I/O通信端口。這些內置功能使設備能夠作為人機界面(HMI)，為操作員提供工廠車間區域的集中監控和控制。

2711-K10C1的彩色顯示屏允許使用彩色編碼設計和動畫創建詳細的過程模擬。此功能提供了更多信息，例如輕松識別管道內流動的材料類型、過程區域的識別、過程警報和事件的識別以及其他相關狀態。顯示屏的有效顯示面積為211 x 158毫米(8.3 x 6.2英寸)，分辨率為640 x 480像素。

對于與過程或機器的接口，可以通過從F1到F16的16個功能鍵啟動控制，這些功能鍵是完全可編程的，無論是本地還是全局分配。功能鍵是不銹鋼圓頂膜，驅動壽命為100萬。

對于數據交換，2711-K10C1具有支持菊花鏈架構的嵌入式遠程I/O (RIO)接口端口。它還有一個板載RS232通信端口，用于將打印隊列發送到警報打印機，用于警報記錄目的。

2711-K10C1終端具有10英寸彩色顯示屏和由功能鍵和導航鍵組成的鍵盤組件。終端支持32種標準顏色，分辨率為640 × 480。它的尺寸為11.11 x 16.64 x 4.40英寸。它重8.2磅。它具有1008 KB的非易失性存儲器，310 KB的RAM和85 – 264V的交流輸入電壓。在通信方面，具有遠程I/O通信端口和RS232打印機通信接口。2711-K10C1具有額定NEMA 12/13或4X外殼，僅用于室內使用。

2711- k10c1支持先進的報警處理來存儲信息，并配有RS-232端口用于在線打印。它還支持各種通用語言。其他功能包括模擬儀表，屏幕安全，存儲卡支持更好的控制。2711- k10c1具有各種端口，可連接到掃描儀，PLC, SLC或Logix控制器。

2711-K10C1 彩色編碼設計和動畫創建詳細的過程模擬

Allen-Bradley 2711-K10C1 is a PanelView standard operator terminal. It specifically falls under the subcategory PanelView 1000 and features a 10-inch, color active matrix TFT screen, keyboard user interface, and remote I/O communication port. These built-in features enable the device to act as a human machine interface (HMI), providing operators with centralized monitoring and control of the plant floor area.

The 2711-K10C1’s color display allows for the creation of detailed process simulations using color-coded design and animation. This feature provides additional information such as easy identification of the type of material flowing in the pipeline, identification of process areas, identification of process alerts and events, and other relevant states. The display has an effective display area of 211 x 158 mm (8.3 x 6.2 inches) and a resolution of 640 x 480 pixels.

For interfaces with processes or machines, control can be initiated with 16 function keys from F1 to F16, which are fully programmable and assigned either locally or globally. The function key is a stainless steel dome membrane with a drive life of 1 million.

For data exchange, the 2711-K10C1 has an embedded remote I/O (RIO) interface port that supports a Daisy chain architecture. It also has an onboard RS232 communication port for sending print queues to the alarm printer for alarm recording purposes.

The 2711-K10C1 terminal features a 10-inch color display and a keyboard assembly consisting of function keys and navigation keys. The terminal supports 32 standard colors with a resolution of 640 × 480. It measures 11.11 x 16.64 x 4.40 inches. It weighs 8.2 pounds. It has 1008 KB of non-volatile memory, 310 KB of RAM and 85-264 V AC input voltage. In terms of communication, it has a remote I/O communication port and RS232 printer communication interface. The 2711-K10C1 has a rated NEMA 12/13 or 4X housing for indoor use only.

The 2711-k10c1 supports advanced alarm processing to store information and is equipped with an RS-232 port for online printing. It also supports a variety of general-purpose languages. Other features include analog meters, screen security, and memory card support for better control. The 2711-k10c1 has a variety of ports for connection to a scanner, PLC, SLC or Logix controller.
