1785-L40B 可編程邏輯控制器(PLC)組件 自動化應用程序

1785-L40B是一個可編程邏輯控制器(PLC)組件。本產品是PLC5系列的控制器。安裝在PLC5機箱上，如1771-A1B、1771-A2B、1771-A3B、1771-A3B1和1771-A4B。

該控制器理想地用于中型到大型自動化應用程序，因?yàn)樗鼉?nèi)置了一個48KWords用戶內存，能夠處理I/O設備的任何組合，總計數為2048個點或2048個輸入和2048個輸出設備，用于補充配置。隨著I/O容量的增加，該控制器還可以處理多達29個PLC 5個機架，由1個本地機架和28個遠程I/O機架組成。本地機架是指控制器所在的機架。

該控制器還內置四(4)DH+或遠程I/O(適配器或掃描儀)組合端口，一(1)串行端口，可配置RS-232和423和RS-422A通信標準。每個組合端口可用于單獨的網絡，允許控制器實現四(4)個獨立的DH+ / RIO網絡。串行通信通道允許點對點接口，這也理想地用于短距離通信。

附加的EEPROM或備份存儲器設備可以被安裝以作為控制器的非易失性存儲器。可用的內存卡有16K字1785-ME16, 532k字1785-ME32, 64K字1785-ME64, 100K字1785-ME100。

1785-L40C15

1785-L40B 可編程邏輯控制器(PLC)組件 自動化應用程序

The 1785-L40B is a programmable logic controller (PLC) assembly. This product is a controller of PLC5 series. Installed on PLC5 chassis such as 1771-A1B, 1771-A2B, 1771-A3B, 1771-A3B1, and 1771-A4B.

The controller is ideal for medium to large automation applications as it has a built-in 48KWords user memory capable of handling any combination of I/O devices, a total number of 2048 points or 2048 input and 2048 output devices for supplemental configuration. With increased I/O capacity, the controller can also handle up to 29 PLC 5 racks, consisting of 1 local rack and 28 remote I/O racks. Local rack refers to the rack where the controller resides.

The controller also has built-in four (4)DH+ or remote I/O(adapter or scanner) combo ports, and one (1) serial port that can be configured with RS-232 and 423 and RS-422A communication standards. Each combined port can be used for a separate network, allowing the controller to implement four (4) separate DH+ / RIO networks. Serial communication channels allow point-to-point interfaces, which are also ideal for short-range communication.

An additional EEPROM or backup memory device can be installed as the controller’s non-volatile memory. Available memory cards are 16K word 1785-ME16, 532k word 1785-ME32, 64K word 1785-ME64, and 100K word 1785-ME100.
