2711-T10C9 嵌入式模擬電阻觸摸屏 有源矩陣薄膜電阻器

Allen-Bradley 2711-T10C9是PanelView 1000標準操作員終端。該操作終端由外部85-264VAC供電電壓供電，具有10.1英寸彩色顯示屏，嵌入式RS232接口，支持DH485和另一個RS232端口用于打印機接口。它有一個模擬電阻觸摸屏操作界面。

Allen-Bradley 2711-T10C9是PanelView Plus 1000彩色操作終端的一部分。2711-T10C9彩色顯示屏可以顯示終端的配置環境，也可以顯示操作終端的運行界面。使用帶有冷陰極熒光(CCF)背光的有源矩陣薄膜電阻器(TFT)，操作終端可用于顯示全彩圖形，并一目了然地顯示高級信息。彩色屏幕可用于顯示儀器和設備的狀態，描繪工藝區域，材料和工廠情況。嵌入式模擬電阻觸摸屏界面的設計允許操作員直接與屏幕上顯示的運行時對象進行交互。與鍵盤終端相比，這是一種更方便的操作2711-T10C9的方法。
2711-T10C9具有位于器件后部的嵌入式電源端子排。它由85-264VAC的外部電壓供電，頻率為43-63 Hz。最大功耗55va，散熱39w (132 BTU/HR)。
2711-T10C9還配備了1008 KB的非易失性閃存，用于位圖、文本和應用程序?qū)ο螅约?10 KB的運行時應用程序內存。如果用戶需要額外的內存，它還支持ATA存儲卡。該終端還配有電池支持的實時時鐘，該時鐘對關鍵數據進行時間戳。它有兩個通信端口，即RS-232 (DH-485)通信端口和RS-232打印機端口。2711-T10C9端子配備NEMA型12/13或4倍外殼，尺寸為11.11 x 14.58 x 4.40英寸，重約3.6公斤或7.9磅。交流電源端子，額定電壓為交流85 ~ 264伏，頻率為47 ~ 63赫茲，最大交流功耗為55va，工作溫度范圍為0 ~ 55攝氏度，非工作溫度范圍為-25 ~ 70攝氏度。該終端還具有5%至95%的非冷凝相對濕度，溫度為0至55攝氏度。
2711-T10C9常見問題解答

2711-T10C9 嵌入式模擬電阻觸摸屏 有源矩陣薄膜電阻器

The Allen-Bradley 2711-T10C9 is part of the PanelView Plus 1000 color operating terminal.
2711-T10C9 Color display can display the configuration environment of the terminal, and can also display the operating interface of the operating terminal. Using an active matrix thin film resistor (TFT) with a cold cathode fluorescence (CCF) backlight, the operating terminal can be used to display full-color graphics and display advanced information at a glance. Color screens can be used to display the status of instruments and equipment, depicting process areas, materials and plant conditions. The embedded analog resistance touch screen interface is designed to allow the operator to interact directly with the runtime objects displayed on the screen. This is a more convenient way to operate the 2711-T10C9 compared to the keyboard terminal.
The 2711-T10C9 has an embedded power terminal block located at the rear of the device. It is powered by an external voltage of 85-264VAC with a frequency of 43-63 Hz. The maximum power consumption is 55va and the heat dissipation is 39w (132 BTU/HR).
The 2711-T10C9 also comes with 1008 KB of non-volatile flash memory for bitmaps, text, and application objects, and 310 KB of runtime application memory. It also supports ATA memory cards if users need additional memory. The terminal is also equipped with a battery-powered real-time clock that timestamps critical data. It has two communication ports, namely RS-232 (DH-485) communication port and RS-232 printer port. The 2711-T10C9 terminals are equipped with NEMA type 12/13 or 4x housing, measuring 11.11 x 14.58 x 4.40 inches and weighing approximately 3.6 kg or 7.9 LBS. The rated voltage of the AC power supply terminal is 85 ~ 264 volts AC, the frequency is 47 ~ 63 Hz, the maximum AC power consumption is 55va, the operating temperature range is 0 ~ 55 degrees Celsius, the non-operating temperature range is -25 ~ 70 degrees Celsius. The terminal also has a non-condensing relative humidity of 5 to 95 percent and a temperature of 0 to 55 degrees Celsius.
2711-T10C9 Frequently Asked Questions
