基本細節:330930-065-01-05 延長電纜設計 接近探頭

330930-065-01-05 3300 NSv 延長電纜設計用于將 3300 NSv 接近探頭連接到近端傳感器（集成在 990 振動變送器中）。這些電纜有 4.0、4.5、6.0 和 6.5 米的長度可供選擇，并包括多種連接器選項。
在確定電纜長度時，重要的是將延長電纜長度與探頭長度相加時等于Proximitor傳感器長度。
3300 XL NS傳感器系統主要用于沉孔、側視或后視限制限制使用標準Bently Nevada 3300和3300 XL5和8 mm傳感器系統的區域。它也是小目標應用的理想選擇，例如測量小于51毫米(2英寸)的軸的徑向振動或小于15米(0.6英寸)的平面目標的軸向位置。它主要用于流體膜軸承機器的以下應用中，其中存在小軸或縮小的側視圖:
徑向振動和徑向位置測量
軸向(推力)位置測量
轉速表和零速測量

相位參考(Keyphasor)信號。3300 XL NSV傳感器系統設計允許其替代3300 RAM傳感器系統和3000系列或7000系列190傳感器系統。從3300 RAM系統升級到3300 XL NSv系統時，可以使用現有的探頭、延長電纜和帶有3300 XL NSv Proximitor傳感器的監控系統。從3000系列或7000系列傳感器系統升級時，必須用NSV組件替換探頭、延長電纜和前置器傳感器。
3300 XLNSv傳感器系統的平均標度因數為7.87 V/mm (200 mV/mi)，這是渦流傳感器最常見的輸出。其增強的側視圖和小目標特性使其比BentlvNevada 3300 X-series 5和8 mm傳感器系統具有更短的線性范圍。1.5毫米(60密耳)的線性范圍超過了3000系列190傳感器系統的線性范圍。

330930-065-01-05

The 330930-065-01-05 3300 NSv extension cable is designed to connect the 3300 NSv proximity probe to the near end sensor (integrated in the 990 vibration transmitter). These cables are available in lengths of 4.0, 4.5, 6.0 and 6.5 meters and include a variety of connector options.
When determining cable length, it is important that the extended cable length equals the Proximitor sensor length when added to the probe length.
The 3300 XL NS sensor system is primarily used in areas where countersunk, side-view or rear-view restrictions restrict the use of standard Bently Nevada 3300 and 3300 XL5 and 8 mm sensor systems. It is also ideal for small target applications, such as measuring the radial vibration of axes less than 51 mm (2 in) or the axial position of planar targets less than 15 m (0.6 in). It is mainly used in the following applications of fluid film bearing machines where small shafts or reduced side views are present:
Radial vibration and radial position measurement
Axial (thrust) position measurement
Tachometer and zero speed measurement

Phase reference (Keyphasor) signal. The 3300 XL NSV sensor system design allows it to replace the 3300 RAM sensor system and the 3000 Series or 7000 Series 190 sensor system. When upgrading from a 3300 RAM system to a 3300 XL NSv system, you can use the existing probe, extension cable, and monitoring system with 3300 XL NSv Proximitor sensor. When upgrading from a 3000 series or 7000 series sensor system, the probe, extension cable, and presensor must be replaced with an NSV assembly.
The 3300 XLNSv sensor system has an average scale factor of 7.87 V/mm (200 mV/mi), which is the most common output for eddy current sensors. Its enhanced side view and small target features give it a shorter linear range than the BentlvNevada 3300 X-series 5 and 8 mm sensor systems. The 1.5 mm (60 mil) linear range exceeds the linear range of the 3000 Series 190 sensor system.
