基本細節:

1756-TBCH 可移動的配線板 現場側接線

該1756-TBCH可拆卸配片板是一個36針籠夾與標準外殼(臂深度為2.5毫米平方)。向RTB發送終止信號時，所需轉矩為0.5 Nm螺桿轉矩。推薦使用直徑3.2 mm的螺絲刀。螺絲刀寬度。它的尺寸為5.51×4.41×5.71英寸。它重0.3磅。布線時，使用額定90度的實心或絞合銅線。194攝氏度。華氏溫度)或更大，尺寸為1.2毫米(3/64英寸)。必須使用最大絕緣。如果是單線連接，線徑必須為0.33- 2.1平方毫米。(22 ~ 14awg)，采用兩線制連接時，線徑為0.33 ~ 1.3 mm2。(22-16美國標準線規)。不要在任何一個端子上連接超過兩根電線。

每個ControlLogix |/0模塊都可以安裝在任何ControlLogix機箱中，它們都需要一個可移動的配線板(RTB)來連接所有現場側接線。每一個!/0模塊有許多應用，從高速數字處理到過程控制，在ControlLogix架構中，使用生產者-消費者技術在相同或不同機箱中的多個控制器之間共享輸入和輸出
狀態。該1756-TBCH RTB適用于清潔和干燥的工業環境，范圍從0到60度。攝氏操作溫度和30g操作沖擊。1756-TBCH是一款36針籠夾可移動終端面板(RTB)，旨在為輸入和輸出設備提供模塊化和靈活的終端。RTB是一個模塊組件，安裝在ControlLogix //O模塊的前端，隱藏在模塊門蓋后面。
RTB必須單獨訂購。根據模塊的不同，需要適當?shù)腞TB。然而，1756- tbch支持大多數1756 ControlLogix模塊

rtb的思想是允許在不需要實際模塊的情況下終止電線。本合同可與RTB單獨解除。一旦完成，RTB可以很容易地附加到主模塊。此外，RTB還節省了故障排除和維護時間，特別是在模塊更換期間。當更換模塊時，整個RTB將從主模塊中卸載。然后將其重新安裝到更換模塊上，而無需重新布線。
SERCOS周期時間@ 8 Mbps
0.5ms，最多4個驅動器(1)
1毫秒，多達8個驅動器
2毫秒，最多16個驅動器

1756-TBCH

The 1756-TBCH detachable mating plate is a 36-pin cage clip with a standard housing (arm depth of 2.5 mm square). When sending the termination signal to the RTB, the required torque is 0.5 Nm screw torque. A screwdriver with a diameter of 3.2 mm is recommended. Screwdriver width. It measures 5.51×4.41×5.71 inches. It weighs 0.3 pounds. For wiring, use solid or stranded copper wire rated at 90 degrees. 194 degrees Celsius. Fahrenheit) or larger, with a size of 1.2 mm (3/64 inch). Maximum insulation must be used. If it is a single wire connection, the wire diameter must be 0.33- 2.1 mm square. (22 to 14awg), when the two-wire connection is adopted, the wire diameter is 0.33 to 1.3 mm2. (22-16 US Standard wire gauge). Do not connect more than two wires to any one terminal.

Each ControlLogix |/0 module can be installed in any ControlLogix chassis, and they all require a removable wiring board (RTB) to connect all field side wiring. Every one of them! The /0 module has many applications, from high-speed digital processing to process control, which in the ControlLogix architecture uses producer-consumer technology to share inputs and outputs between multiple controllers in the same or different chassis
Status. The 1756-TBCH RTB is suitable for clean and dry industrial environments ranging from 0 to 60 degrees. Celsius operating temperature and 30g operating impact. The 1756-TBCH is a 36-pin cage clamped Removable terminal panel (RTB) designed to provide a modular and flexible terminal for input and output devices. The RTB is a module component that is installed on the front end of the ControlLogix //O module, hidden behind the module door cover.
RTB must be ordered separately. Depending on the module, the appropriate RTB is required. However, the 1756-TBCH supports most 1756 ControlLogix modules

The idea of rtb is to allow the wire to be terminated without the need for an actual module. This contract may be terminated separately from RTB. Once complete, RTB can be easily attached to the main module. In addition, RTB saves time for troubleshooting and maintenance, especially during module replacement. When a module is replaced, the entire RTB is uninstalled from the main module. It is then reinstalled onto the replacement module without the need for rewiring.
SERCOS cycle time @ 8 Mbps
0.5ms, up to 4 drives (1)
1 millisecond, up to 8 drives
2 milliseconds, up to 16 drives
