基本細節:IC693BEM341 可編程邏輯控制器 總線接口單元

該IC693BEM341是工廠儀表協議 （FIP） 兼容模塊，屬于艾默生自動化的 90-30 系列可編程邏輯控制器 （PLC） 系列，以前由 GE Fanuc Automation 制造。該模塊是對之前總線控制器的升級，因為IC693BEM341的數據速率為 2.5 MHz。該IC693BEM341特別帶有三 （3） 個內置通信接口、兩 （2） 個 9 針 D 外殼 FIP 總線連接器和一 （1） 個 RS485 通信接口，用于通過固件修改進行軟件升級。該模塊還安裝了六 （6） 個 LED 狀態指示燈，例如通道 1 的模塊正常、運行、載波檢測;通道 2 的載波檢測;通道 1 啟用傳輸，通道 2 啟用傳輸。該 FIB 總線控制器模塊設計用于通過 FIB 總線到 FIP 總線接口與各種設備連接，例如 90-70 系列 PLC;通過現場控制 I/O 模塊通過 Filed 總線接口單元 （BIU） 的現場控制站;遠程 I/O 通過 FIP 遠程 I/O 掃描器模塊和使用 FIP 接口模塊的通用設備掉線。IC693BEM341需要 90-30 系列 CPU，版本為 8.0 或更高版本。對于配置，該模塊需要使用手持式編程器 （HHP）、Windows 編程軟件 IC641CTLxxx Release 2.0 或更高版本或 FBCLOAD 配置實用程序?qū)⒂行渲孟螺d到模塊。該模塊的附加功能包括顯示固件版本、多達 1024 個布爾值的時間戳和模式 30（包括冗余、從 I/O 設備管理、時間戳、消息服務、MIPS 同步交換和外部配置接收）的功能。
IC693BEM341控制器是由GE Fanuc設計和制造的FIP總線控制器。這部分屬于GE系列90-30。這種特定的控制器型號是對舊總線控制器的升級，它包括不同的創新功能。將此型號與 GE 340 控制器等舊型號進行比較時，它們在功能上是相同的，只是在新的 IC693BEM341 型號中提高了網絡速度。GE Fanuc IC693BEM341 FIP 總線控制器是總線控制器的 2.5 兆赫茲版本。它也適用于固件版本 3.01。此總線控制器需要任何 IC693 PLC CPU 版本為 8.10 或更高版本。該現場總線控制器的另一個配置要求是它需要手持式編程器或 HHP。此 HHP 具有由 Windows 開發的編程軟件，它應該是 2.0 或更高版本。必須使用 FBCLOAD 配置實用程序來配置控制器以在網絡上正常運行。
IC693BEM341 FIP 總線控制器支持配置模式 30。此模式是配置模式 11 與以前的總線控制器版本相比的擴展，它為包括 I/O 嵌套、驅動器、PLC 和控制站在內的從屬設備添加了冗余、管理和監控功能等不同功能。它還可以對布爾值進行時間戳，并通過 FIP 網絡處理消息傳遞服務和外部配置的接收。GE Fanuc FIP 總線控制器中提供的一些更正是為了解決之前的問題，該問題導致 PLC CPU 在沒有此類故障時報告的模塊故障丟失。另一個已得到糾正的問題是，PLC應用的狀態經常被錯誤地確定。

IC693BEM341

The IC693BEM341 is a Factory Instrumentation Protocol (FIP) compatible module that belongs to Emerson Automation’s Series 90-30 Programmable Logic controller (PLC) family and was previously manufactured by GE Fanuc Automation. This module is an upgrade over the previous bus controller, as the IC693BEM341 has a data rate of 2.5 MHz. The IC693BEM341 specifically comes with three (3) built-in communication interfaces, two (2) 9-pin D-housing FIP bus connectors, and one (1) RS485 communication interface for software upgrades via firmware modifications. The module is also equipped with six (6) LED status indicators, such as channel 1 module normal, operation, carrier detection; Carrier detection of channel 2; Channel 1 enables transmission and channel 2 enables transmission. The FIB bus controller module is designed to connect to various devices, such as 90-70 series PLCS, via the FIB bus to FIP bus interface; Field control station via field control I/O module via field bus interface unit (BIU); Remote I/O The FIP remote I/O scanner module and common devices using the FIP interface module are disconnected. The IC693BEM341 requires a 90-30 series CPU with version 8.0 or later. For configuration, the module needs to download the valid configuration to the module using a handheld programmer (HHP), Windows programming software IC641CTLxxx Release 2.0 or later, or the FBCLOAD configuration utility. Additional features of the module include the ability to display firmware versions, time stamps of up to 1024 Booleans, and mode 30, including redundancy, slave I/O device management, time stamps, message services, MIPS synchronous exchange, and reception of external configurations.
The IC693BEM341 controller is a FIP bus controller designed and manufactured by GE Fanuc. This part belongs to the GE series 90-30. This particular controller model is an upgrade over the old bus controller and it includes different innovative features. When comparing this model with older models such as the GE 340 controller, they are functionally identical except for the increased network speed in the new IC693BEM341 model. The GE Fanuc IC693BEM341 FIP bus controller is a 2.5 MHZ version of the bus controller. It is also available with firmware version 3.01. This bus controller requires any IC693 PLC CPU version 8.10 or later. Another configuration requirement for this fieldbus controller is that it requires a handheld programmer or HHP. This HHP has programming software developed by Windows and it should be version 2.0 or later. The FBCLOAD configuration utility must be used to configure the controller to function properly on the network.
The IC693BEM341 FIP Bus controller supports configuration mode 30. This mode is an extension of Configuration Mode 11 compared to previous versions of the bus controller, which adds different features such as redundancy, management, and monitoring functions to slave devices including I/O nesting, drives, PLCS, and control stations. It can also timestamp Booleans and handle the reception of messaging services and external configurations over the FIP network. Some of the corrections provided in the GE Fanuc FIP bus controller are designed to address a previous issue that caused the PLC CPU to lose module failures reported when there were no such failures. Another problem that has been corrected is that the status of PLC applications is often incorrectly determined.
