基本細節:126599-01 四通道儀器 專為航空衍生燃?xì)廨啓C而設計

規格
產品編號： 126599-01
制造商： Bently Nevada
系列： 3500
產品類型： Aero GT I/O 模塊（內部端接）
可用性： 現貨
尺寸：241.3 mm x 24.4 mm x 99.1mm
重量： 0.45 kg 原
產地：美國
126599-01是由Bently Nevada開發的Aero GT I/O模塊。它是 3500/44M Aeroderivitive GT 振動監測系統的一部分。四通道 3500/44M Aeroderivitive GT 振動監測儀是一款專為航空衍生燃?xì)廨啓C而設計的儀器。它通過將觀察到的參數與預定義的警報設定值進行比較來驅動警報，以持續監控機器。它將關鍵的機器信息傳達給從事操作和維護工作的員工。3500/44M 上的 Aero GT I/O 模塊使用 Bently Nevada 接口模塊連接到 Velomitor 傳感器和加速度計。顯示器通過 Prox/Velom I/O 連接。
126599-01 產品特點
3500/44M Aeroderivitive GT 振動監測儀是一款專為航改型燃?xì)廨啓C應用而設計的四通道儀器。它通過將監控參數與配置的報警設定值進行比較來持續監控機器以生成報警。
GT 振動監測器將關鍵的機器信息傳達給操作和維護人員。3500/44M 上的 Aero GT I/O 模塊通過 Bently Nevada 接口模塊與 Velomitor 傳感器和加速度計進行通信。
126599-01 功能描述
您可以使用 3500 機架配置軟件為以下過濾器選項配置 3500/44M Aeroderivitive GT 振動監測器：
信號集成
1倍振動跟蹤
帶通振動
3500/44M Aeroderivitive GT 振動監測器接受兩個獨立的 Keyphasor 信號作為輸入，允許每個通道對使用不同的跟蹤濾波器。多模通道可配置多達八組報警參數，包括報警和危險設定點以及報警時間延時。每套設備都可以根據特定的機器模式進行定制。當機器通過使用多模 I/O 模塊上的觸點或通過通信網關的軟件命令更改模式時，監視器可以切換到特定的設置。
特性
尺寸
高 x 寬 x 深 – 241.3 mm x 24.4 mm x 99.1mm
重量
0.45 千克（1.0 磅）
機架空間要求
1 個全高后插槽

126599-01

specification
Product Number: 126599-01
Manufacturer: Bently Nevada
Series: 3500
Product Type: Aero GT I/O Module (Internal termination)
Availability: In stock
Dimensions: 241.3mm x 24.4mm x 99.1mm
Weight: 0.45kg raw
Origin: USA
The 126599-01 is an Aero GT I/O module developed by Bently Nevada. It is part of the 3500/44M Aeroderivitive GT vibration monitoring system. The four-channel 3500/44M Aeroderivitive GT vibration monitor is an instrument specifically designed for use with aviation-derived gas turbines. It drives the alarm by comparing the observed parameters to predefined alarm setpoints to continuously monitor the machine. It communicates critical machine information to employees engaged in operations and maintenance. The Aero GT I/O module on the 3500/44M connects to the Velomitor sensor and accelerometer using the Bently Nevada interface module. The display is connected via Prox/Velom I/O.
126599-01 Product features
The 3500/44M Aeroderivitive GT vibration Monitor is a four-channel instrument designed specifically for aircraft modified gas turbine applications. It continuously monitors the machine to generate alarms by comparing the monitoring parameters to the configured alarm Settings.
The GT vibration monitor communicates critical machine information to operations and maintenance personnel. The Aero GT I/O module on the 3500/44M communicates with the Velomitor sensor and accelerometer via the Bently Nevada interface module.
126599-01 Function Description
You can configure the 3500/44M Aeroderivitive GT vibration monitor using the 3500 rack configuration software for the following filter options:
Signal integration
1 times vibration tracking
Band-pass vibration
The 3500/44M Aeroderivitive GT vibration monitor accepts two independent Keyphasor signals as input, allowing different tracking filters to be used for each channel pair. The multimode channel can be configured with up to eight sets of alarm parameters, including alarm and hazard set points and alarm time delay. Each set of equipment can be customized to a specific machine pattern. When the machine changes the mode by using contacts on the multimode I/O module or through software commands on the communication gateway, the monitor can be switched to a specific setting.
peculiarity
dimension
Height x Width x Depth – 241.3mm x 24.4mm x 99.1mm
weight
0.45 kg (1.0 lb)
Rack space requirement
1 full height rear slot
