基本細節:1746-HSCE 高速計數器模塊 單端接線的標稱輸入電壓為 0-5VDC
1746-HSCE是一個高速計數器模塊。該模塊是SLC500可編程邏輯控制器(PLC)平臺的一部分。它具有雙向計數功能,并帶有輸入A, B和Z,與5VDC差分輸入和0-5VDC單端輸入的標稱信號電壓兼容,最大輸入頻率為50 kHz。它也有一個限位開關輸入和四(4)開路集電極輸出。它可以配置為在范圍,鼠和測序模式下操作。
1746-HSCE 用于雙向計數要求、運動檢測、累加和其他需要處理高速離散輸入的應用。該模塊通常用于工廠自動化應用,但高度適用于過程自動化要求。該高速計數器模塊可以配置為在不同的模式下運行,例如范圍模式、速率模式和定序器模式。
1746-HSCE 具有輸入 A、B 和 Z,差分接線的標稱輸入電壓為 5VDC, 。它接受的最小脈沖寬度為 10 μs,脈沖間隔為 4.5 μs。這些輸入集的可接受輸入頻率取決于模塊的配置模式。在時序控制器模式下工作時,兼容的最大輸入頻率為 50 kHz,在范圍速率模式下工作時為 32,767kHz。此外,1746-HSCE還具有限位開關輸入,導通狀態電壓范圍分別為3.8-5.4VDC、9.4-16.5VDC和16.5-30VDC @ 5VDC、12VDC和24VDC標稱電壓。
1746-HSCE 還具有四 (4) 個集電極開路輸出,可在 4.5 至 10V 直流和(開關 2 打開)和 10 至 30V 直流(開關 2 關閉)的電壓電平下工作,導通狀態電流額定值為 4.5V 直流時為 16 mA,10V 直流時為 40 mA,10V 直流時為 40 mA,30V 直流時為 125 mA。
對于故障排除和診斷,它具有內置診斷 LED,例如 CPU 故障 LED、故障代碼、錯誤代碼。它還具有駐留在輸入數據文件中的內部狀態字。它旨在用于工業環境,必須安裝在 NEMA 級外殼中。

1746-HSCE
The 1746-HSCE is a high-speed counter module. The module is part of the SLC500 Programmable Logic Controller (PLC) platform. It has bidirectional counting and comes with inputs A, B, and Z, compatible with nominal signal voltages for 5VDC differential inputs and 0-5VDC single-ended inputs, with a maximum input frequency of 50 kHz. It also has a limit switch input and four (4) open collector outputs. It can be configured to operate in range, mouse, and sequencing modes.
The 1746-HSCE is used for bidirectional counting requirements, motion detection, accumulation, and other applications where high-speed discrete inputs need to be processed. This module is typically used for factory automation applications, but is highly suitable for process automation requirements. The high-speed counter module can be configured to operate in different modes, such as range mode, rate mode, and sequencer mode.
The 1746-HSCE has inputs A, B, and Z with nominal input voltages of 5VDC for differential wiring and 0-5VDC for single-ended wiring. It accepts a minimum pulse width of 10 μs and a pulse interval of 4.5 μs. The acceptable input frequency of these input sets depends on the configuration mode of the module. The maximum compatible input frequency is 50 kHz when operating in timing controller mode and 32,767kHz when operating in range rate mode. In addition, the 1746-HSCE has a limit switch input with on-state voltage ranges of 3.8-5.4VDC, 9.4-16.5VDC and 16.5-30VD@5VDC, 12VDC and 24VDC nominal voltages, respectively.
The 1746-HSCE also has four (4) collector open-circuit outputs that operate at voltage levels of 4.5 to 10V DC and (switch 2 on) and 10 to 30V DC (switch 2 off), with on-state current ratings of 16 mA at 4.5V DC, 40 mA at 10V DC, 40 mA at 10V DC, and 125 mA at 30V DC.
For troubleshooting and diagnostics, it has built-in diagnostic leds, such as CPU failure leds, fault codes, error codes. It also has an internal status word that resides in the input data file. It is intended for use in industrial environments and must be installed in a NEMA grade housing.
