基本細節:4WE6D62EG24N9K4 電磁換向閥 適用于各種液壓控制需求

4WE6D62/EG24N9K4是力士樂（Rexroth）品牌下的一款電磁換向閥。這款換向閥具有多種特點和功能，適用于各種液壓控制需求。
首先，從型號名稱中我們可以獲取一些基本信息。其中，“4WE”表示這是一個電磁換向閥，“6D62”代表特定的閥芯系列和型號，“EG24”表示采用高功能濕式電磁鐵，直流電壓為24V，“N9”表示配有隱蔽式手動應急操作裝置，“K4”表示連接方式符合特定的設備插頭標準。
這款電磁換向閥具有多種優點。它的最大工作壓力可達350 bar，最大流量分別為80 l/min（直流）和60 l/min（交流），能夠滿足大部分液壓系統的需求。同時，它提供三位四通、二位四通或二位三通型號，使得用戶可以根據具體需求選擇最合適的型號。
此外，4WE6D62/EG24N9K4電磁換向閥采用ISO 4401-03-02-0-05標準的油口安裝面，方便與其他液壓元件的連接。同時，它配備了高功率線圈，線圈可選旋轉90°，使得安裝和連接更加便捷。電氣連接方面，該閥可以單個或?qū)χ羞B接，適應不同的操作需求。
為了滿足用戶的特定需求，4WE6D62/EG24N9K4電磁換向閥還可以根據要求選配輔助操縱裝置和閥芯位置監控功能，增加了其應用的靈活性。
總的來說，4WE6D62/EG24N9K4電磁換向閥是一款功能強大、靈活多樣的液壓控制元件，適用于各種需要精確和穩定液壓控制的工程應用。無論是單獨使用還是與其他液壓元件配合使用，它都能提供可靠的液壓控制解決方案。

4WE6D62EG24N9K4

The 4WE6D62/EG24N9K4 is an electromagnetic directional valve under the Rexroth brand. This reversing valve has a wide range of features and functions for a wide range of hydraulic control needs.
First, we can get some basic information from the model name. Among them, “4WE” means that this is an electromagnetic reversing valve, “6D62” represents a specific spore series and model, “EG24” means that the use of high-function wet electromagnet, DC voltage is 24V, “N9” means that it is equipped with a concealed manual emergency operation device, “K4” means that the connection method meets the specific equipment plug standards.
This solenoid directional valve has several advantages. With a maximum operating pressure of 350 bar and a maximum flow rate of 80 l/min (DC) and 60 l/min (AC), it can meet the needs of most hydraulic systems. At the same time, it offers three four-way, two four-way or two three-way models, allowing users to choose the most suitable model according to their specific needs.
In addition, the 4WE6D62/EG24N9K4 solenoid directional valve uses the ISO 4401-03-02-0-05 standard oil port mounting surface for easy connection with other hydraulic components. At the same time, it is equipped with a high power coil, the coil can be rotated 90 degrees, making installation and connection more convenient. In terms of electrical connection, the valve can be connected individually or in pairs to adapt to different operating requirements.
In order to meet the specific needs of users, the 4WE6D62/EG24N9K4 solenoid directional valve can also be selected according to the requirements of the auxiliary control device and spool position monitoring function, increasing the flexibility of its application.
Overall, the 4WE6D62/EG24N9K4 solenoid directional valve is a powerful and versatile hydraulic control element suitable for a variety of engineering applications requiring accurate and stable hydraulic control. Whether used alone or in combination with other hydraulic components, it provides a reliable hydraulic control solution.
