基本細節:1783-US6T2TGH2H 以太網交換機 共有 10 個可用端口

1783-US6T2TG2H 以太網交換機是 Stratix 2000 系列中提供的一種非管理型 Allen-Bradley/Rockwell 自動化以太網交換機。它是一個 10 端口非管理型以太網交換機。1783-US6T2TG2H 非網管型以太網交換機配備 6 個快速以太網端口、2 個千兆以太網端口和 2 個多模 SFP 快速以太網端口。這種非網管型以太網交換機可在 -40 至 167 華氏度、5% 至 95% 的非冷凝相對濕度下運行。當不使用 1783-US6T2TG2H 非網管型以太網交換機時，它可以存儲在 -40 至 185 華氏度，也可以存儲在 5% 至 95% 的非冷凝相對濕度下。
它共有 10 個可用端口，其中 6 個快速以太網 + 2 個千兆以太網 RJ45 端口和 2 個快速以太網單模預裝光纖 SFP 模塊 SFP 端口。請注意，如果要將 SFP 模塊與交換機一起使用，則需要單獨購買它們。對于10/100/1000 Mbps，其廣播風暴閾值（特別是在每秒數據包數方面）為128 pps。此交換機帶有綠色/黃色狀態指示燈，可讓您查看其電源狀態、端口速度狀態和網絡狀態。請注意，1783-US6T2TG2H 交換機具有開放式外殼。使用接地連接時，電線應為 2.5 mm2 （14 AWG） 銅線，當與合適的環形端子一起使用時，該銅線適用于外殼外部周圍溫度以上 187 ??F。對于直流電源連接，所需的電線尺寸為 4-0.25 mm2 （12-24 AWG） 雙絞線銅線，也適用于外殼外部周圍環境溫度以上 187 ??F。
該 B 系列開關的電源輸入為 24V（12-48V DC、18-30V AC、50-60 Hz），最大功耗為 7.5 W，最大浪涌電流為 1.83 A。1783-US6T2TG2H 的額定電流為 450 mA（直流）和 900 mA（交流），而其最大電流為 850 mA（直流）和 1700 mA（交流）。
其工作溫度為 -40-167 ??F，最高環境溫度為 167 ??F，周圍最高空氣溫度為 167 ??F，存儲溫度為 -40-185 ??F。該開關具有 5-95% 的非冷凝相對濕度。1783-US6T2TG2H在10-500 Hz時的工作振動為2 g，工作沖擊為15 g，非工作沖擊為30 g。

1783-US6T2TGH2H

The 1783-US6T2TG2H Ethernet switch is an unmanaged Allen-Bradley/Rockwell automated Ethernet switch offered in the Stratix 2000 series. It is a 10-port unmanaged Ethernet switch. The 1783-US6T2TG2H unmanaged Ethernet switch is equipped with 6 fast Ethernet ports, 2 Gigabit Ethernet ports, and 2 multi-mode SFP fast Ethernet ports. This unmanaged Ethernet switch can operate at -40 to 167 degrees Fahrenheit and 5 to 95 percent non-condensing relative humidity. When not in use, the 1783-US6T2TG2H unmanaged Ethernet switch can be stored at -40 to 185 degrees Fahrenheit, or at 5% to 95% non-condensing relative humidity.
It has a total of 10 available ports, of which 6 fast Ethernet + 2 Gigabit Ethernet RJ45 ports and 2 fast Ethernet single-mode pre-installed optical fiber SFP module SFP ports. Note that if you want to use SFP modules with switches, you will need to purchase them separately. For 10/100/1000 Mbps, the broadcast storm threshold (especially in terms of the number of packets per second) is 128 pps. This switch has a green/yellow status indicator that allows you to view its power status, port speed status, and network status. Please note that the 1783-US6T2TG2H switch has an open housing. When using a ground connection, the wire should be 2.5 mm2 (14 AWG) copper wire which, when used with a suitable ring terminal, is suitable for temperatures above 187 E? F around the outside of the housing. For DC power connections, the required wire size is 4-0.25 mm2 (12-24 AWG) twisted pair copper wire, also suitable for ambient temperatures above 187 E? F outside the housing.
The B-series switch has a power input of 24V (12-48V DC, 18-30V AC, 50-60 Hz), a maximum power consumption of 7.5W, and a maximum inrush current of 1.83A. The 1783-US6T2TG2H is rated at 450 mA (DC) and 900 mA (AC), while its maximum current is 850 mA (DC) and 1700 mA (AC).
The operating temperature is -40-167 E? F, the maximum ambient temperature is 167 E? F, the maximum ambient air temperature is 167 E? F, and the storage temperature is -40-185 E? F. The switch has a non-condensing relative humidity of 5-95%. The 1783-US6T2TG2H has a working vibration of 2 g at 10-500 Hz, a working shock of 15 g, and a non-working shock of 30 g.
