基本細節:330105-02-12-15-02-05 8毫米探頭 機械配置

330105-02-12-15-02-05
3300 XL 8毫米接近傳感器系統包括:
一個3300 XL 8毫米探頭，
一根3300 XL延長線1，和
一個3300 XL Proximitor Sensor2。
該系統提供的輸出電壓與探頭尖端和觀察到的導電表面之間的距離成正比，可以測量靜態(位置)和動態(振動)值。該系統的主要應用是振動和定位
流體膜軸承機械的測量，以及關鍵相量參考和速度測量。
3300 XL 8毫米系統在我們的渦流接近傳感器系統中提供了最先進的性能。標準的3300 XL 8毫米5米系統在機械配置、線性范圍、精度和溫度穩定性方面也完全符合美國石油協會(API)670標準。所有3300 XL 8毫米近距離傳感器系統都提供這種性能水平，并支持探頭、延長電纜和Proximitor傳感器的完全互換性，無需匹配或臺式校準單個組件。每個3300 XL 8毫米傳感器系統組件向后兼容和可互換4與其他非XL 3300系列5毫米和8毫米傳感器系統
components5。這種兼容性包括3300 5毫米探頭，適用于8毫米探頭對可用安裝空間太大的應用6,7

330105-02-12-15-02-05

330105 – the 02-12-15-02-05
3300 XL 8mm proximity sensor system includes:
A 3300 XL 8mm probe,
A 3300 XL extension cord 1, and
A 3300 XL Proximitor Sensor2.
The system provides an output voltage that is proportional to the distance between the probe tip and the observed conductive surface, allowing both static (position) and dynamic (vibration) values to be measured. The main applications of the system are vibration and positioning
Measurement of fluid film bearing machinery, as well as critical phasor references and velocity measurements.
The 3300 XL 8mm system offers state-of-the-art performance in our vortex proximity sensor system. The standard 3300 XL 8 mm 5 m system is also fully compliant with the American Petroleum Institute (API)670 standard in terms of mechanical configuration, linear range, accuracy and temperature stability. All 3300 XL 8mm proximity sensor systems offer this level of performance and support full interchangeability of the probe, extension cable and Proximitor sensors without the need to match or benchtop calibrate individual components. Each 3300 XL 8mm sensor system component is backward compatible and interchangeable with other non-XL 3300 series 5mm and 8mm sensor systems
components5. This compatibility includes 3300 5 mm probes for applications where 8 mm probes have too much available mounting space 6,7
