基本細節:1769-OW8-CC 8通道模擬電壓輸出模塊 具有鎖功能

1769-OW8-CC i / o模塊，8路常開輸出，5 – 265vac, 5 – 125vdc, 16a
1769 – of8v CompactLogix 8通道模擬電壓輸出模塊,8。單端;模擬正常工作范圍:±10 v直流,0至10 v直流,0至5 v直流,1至5 v直流;滿量程模擬量程:±10.5 v, -0.5至10.5 v, -0.5至5.25 v, 0.5至5.25 v直流;全范圍數字分辨率:16位加號(雙極性)
每個I/O模塊包括一個內置的可移動終端塊與手指安全蓋連接到I/O傳感器和執行器。的
終端模塊位于模塊前面的一扇門后面。I/O接線可以從模塊下方布線到I/O終端。

?一旦模塊鎖在一起，系統就變成了一個
崎嶇的組裝。
?上下舌槽引導模塊
在安裝和連接模塊到系統。
?可拆卸端子塊有助于簡化布線任務。
?自升式現場接線壓力板，縮短安裝時間。
?具有鎖功能的專利總線連接器使
一致和系統的溝通。
?模塊正面提供顏色條。
?數字和現場電路是光學隔離的

1769-OW8-CC

1769-OW8-CC i/o module, 8-channel normally open output, 5-265vac, 5-125vdc, 16a
1769-of8v CompactLogix 8-channel analog voltage output module,8. Single-ended; Analog normal operating range :±10 v DC,0 to 10 v DC,0 to 5 v DC,1 to 5 v DC; Full scale analog range :± 10.5v, -0.5 to 10.5v, -0.5 to 5.25v, 0.5 to 5.25v DC; Full range digital resolution: 16-bit plus sign (bipolar)
Each I/O module includes a built-in removable terminal block with a finger safety cover connected to the I/O sensor and actuator. the
The terminal module is located behind a door on the front of the module. I/O wiring can be routed from the bottom of the module to the I/O terminal.
Once the modules are locked together, the system becomes one

Rugged assembly.
? Upper and lower lingual groove guide module
Install and connect modules to the system.
? Detachable terminal blocks help simplify wiring tasks.
? Jack-up field wiring pressure plate, shorten installation time.
? Patented bus connector with lock function
Consistent and systematic communication.
? Color bars are provided on the front of the module.
? Digital and field circuits are optically isolated
