基本細節:1769-OW16 緊湊型 I/O 擴展模塊 用于 5 – 265VAC 和 5 – 125V DC 的工作電壓范圍

1769-OW16 是緊湊型 I/O 擴展模塊。該模塊有十六 （16） 個繼電器輸出通道。該模塊設計用于 5 – 265VAC 和 5 – 125V DC 的工作電壓范圍。模塊兼容 MicroLogix 1500 和 CompactLogix 控制器。
該模塊的觸點額定值為 0.22 A（125 伏直流電）、28VA 和 7.5 A（240 伏交流電）、1800VA 和 0.75 安培（240 伏交流電）、180VA 斷路。其工作電壓范圍為 5 至 265 伏交流電和 5 至 125 伏直流電。該模塊的電流消耗在 24 伏時為 180 mA，在 5.1 伏時為 205 mA。它還具有每個模塊 20A 的最大電流和每個點的最大 2.5A 最大電流。1769-OW16 模塊的最大功耗為 4.75 瓦，最大關斷狀態泄漏為 0 mA，最小導通電流為 10 mA（5 伏直流）。它的工作溫度范圍為 0 至 60 攝氏度，非冷凝相對濕度范圍為 5 至 95%。

1769-OW16模塊的工作沖擊約為30G，在工作時可以承受約2G的振動。請注意，此模塊在打開和關閉狀態下的延遲為 10 毫秒。1769-OW16 具有靈活性，與各種應用兼容，例如 CompactLogix 控制器。此外，1769-OW16 可用作 MicroLogix 1500 控制器組件中的擴展 I/O，以及具有 1769-ADN DeviceNet 或 1769-AENTR 以太網適配器的組件。

1769-OW16 I/O 設備需要自己的電源，除非連接到 MicroLogix 1500 底座。22 至 14 AWG 實心電纜或 22 至 16 AWG 絞合連接電纜可用于 1769-OW16 模塊。它的電源距離額定值為 8 個模塊。與此模塊兼容的唯一電源是 1769-PA2、1769-PB2、1769-PA4 和 1769-B4，并且只能與面板或 DIN 導軌安裝一起安裝。1769-OW16 模塊的近似尺寸為 4.65 x 2.07 x 3.43 英寸，使用 138 毫米安裝卡舌時高度增加到 5.43 英寸。該模塊的重量約為 2 磅。

1769-OW16 是一款十六 （16） 通道繼電器輸出模塊。該模塊由 Allen-Bradley 為 1769 CompactLogix 產品系列制造。該模塊有兩 （2） 組，每組八 （8） 個通道。該輸入組是單獨隔離的，允許該組在不同或相似的電壓類別下工作。
該模塊具有十六 （16） 個 A 型干觸點，每個通道每個點的電流高達 2.5A。這使得該模塊能夠驅動具有更高額定電流的電氣和感性負載。該模塊也適用于在不同電壓類別下運行的系統。
1769-OW16 連接到 MicroLogix 或 CompactLogix 通信總線。將此模塊安裝到控制器組件中的任何相鄰模塊。通信總線還承載為緊湊型 I/O 模塊供電的電源電壓。它在任一控制器系統的機箱中占據單個插槽。

1769-OW16

The 1769-OW16 is a compact I/O expansion module. The module has sixteen (16) relay output channels. The module is designed for operating voltage ranges from 5-265VAC and 5-125V DC. Modules are compatible with MicroLogix 1500 and CompactLogix controllers.
The module has contact ratings of 0.22A (125 volts DC), 28VA and 7.5A (240 volts AC), 1800VA and 0.75 amps (240 volts AC), 180VA break. Its operating voltage ranges from 5 to 265 volts AC and 5 to 125 volts DC. The current consumption of this module is 180 mA at 24 volts and 205 mA at 5.1 volts. It also has a maximum current of 20A per module and a maximum current of 2.5A per point. The 1769-OW16 module has a maximum power consumption of 4.75 watts, a maximum turn-off leakage of 0 mA, and a minimum conduction current of 10 mA (5 volts DC). It operates in a temperature range of 0 to 60 degrees Celsius and a non-condensing relative humidity range of 5 to 95%.

The 1769-OW16 module has an operating shock of about 30G and can withstand vibrations of about 2G when operating. Note that this module has a delay of 10 milliseconds in the open and closed states. The 1769-OW16 is flexible and compatible with a variety of applications, such as CompactLogix controllers. In addition, the 1769-OW16 is available as extended I/O in the MicroLogix 1500 controller assembly, as well as components with a 1769-ADN DeviceNet or 1769-AENTR Ethernet adapter.

1769-OW16 I/O devices require their own power supply unless connected to a MicroLogix 1500 dock. 22 to 14 AWG solid cables or 22 to 16 AWG stranded connection cables are available for 1769-OW16 modules. It has a power distance rating of 8 modules. The only power supplies compatible with this module are 1769-PA2, 1769-PB2, 1769-PA4, and 1769-B4, and can only be installed with a panel or DIN rail mount. The 1769-OW16 module has an approximate size of 4.65 x 2.07 x 3.43 inches, with the height increased to 5.43 inches with the 138 mm mounting latch. The module weighs about 2 pounds.

The 1769-OW16 is a sixteen (16) channel relay output module. The module was manufactured by Allen-Bradley for the 1769 CompactLogix product family. The module has two (2) groups of eight (8) channels each. The input group is individually isolated, allowing the group to operate under different or similar voltage classes.
The module has sixteen (16) A-type dry contacts with A current of up to 2.5A per point per channel. This enables the module to drive electrical and inductive loads with higher current ratings. The module is also suitable for systems operating in different voltage classes.
1769-OW16 connects to the MicroLogix or CompactLogix communication bus. Install this module to any adjacent module in the controller assembly. The communication bus also carries the power supply voltage that powers the compact I/O module. It occupies a single slot in the chassis of either controller system.
