產品描述
東芝2N3A8204-B是一款高速開關晶體，專為電源電路和其他高頻應用而設計。它被安置在一個小的表面安裝包，便于安裝和節省空間的設計。
2N3A8204-B
產品參數
集電極基極電壓:60v
集電極-發射極電壓:50v
發射-基極電壓:6v
集電極電流:0.1 A
總功耗:1500mw
工作溫度范圍:-55℃~ +150℃
2N3A8204-B
規范
高速開關
小表面貼裝封裝
低集電極-發射極飽和電壓
高電流增益
低噪聲
高放大
應用程序
電源電路
高頻電路
通用放大器
開關電路
音頻電路
直流-直流轉換器
電壓調節器
電機控制電路
2N3A8204-B
Product Description
The TOSHIBA 2N3A8204-B is a high-speed switching transistor designed for use in power supply circuits and other high-frequency applications. It is housed in a small surface-mount package for easy installation and space-saving designs.
Product Parameters
Collector-Base Voltage: 60 V
Collector-Emitter Voltage: 50 V
Emitter-Base Voltage: 6 V
Collector Current: 0.1 A
Total Power Dissipation: 1500 mW
Operating Temperature Range: -55 to +150°C
Specifications
High-speed switching
Small surface-mount package
Low collector-emitter saturation voltage
High current gain
2N3A8204
Low noise
High hFE
Applications
Power supply circuits
High-frequency circuits
General-purpose amplifiers
Switching circuits
Audio circuits
DC-DC converters
Voltage regulators
Motor control circuits
