SCHNEIDER ?140CPU67160C ?通訊總線模塊

SCHNEIDER ?140CPU67160C ?通訊總線模塊產品詳情

制造業：在制造業中，該通訊總線模塊可用于集成和控制各種自動化設備和系統，如機器人、生產線、傳感器、執行器等。它可以與其他設備進行通信，實現數據傳輸和協調操作，提高生產效率和質量。

工業控制系統：通訊總線模塊可與其他控制設備和儀表配合使用，實現對工業過程的監控和控制。它可以接收和發送數據，實現與PLC（可編程邏輯控制器）、DCS（分布式控制系統）等系統的通信，確保設備之間的協調運行。

140CPU67160C

能源管理：在能源管理領域，該通訊總線模塊可用于集成能源監測和管理系統。它可以與能源計量儀表、電力監控設備等進行通信，實現能源數據的采集、分析和控制，幫助優化能源使用、提高能源效率。

樓宇自動化：通訊總線模塊可以用于樓宇自動化系統，用于集成和控制建筑物的各種設備和系統，如照明、空調、安防、消防等。它可以與不同的樓宇設備進行通信，實現集中控制和監測，提高建筑物的運行效率和舒適度。
以太網固件

盡管以太網允許通過網絡進行遠程訪問上傳/下載過程，我們強烈建議安裝在僅由CPU、電源和機架。一旦完成，使用僅包含IP的空程序配置PLC系統地址配置。請注意，以太網模塊必須位于同一個邏輯以太網網絡比帶有操作系統加載程序的PC（用于兩個IP地址、子網掩碼和默認網關必須兼容）。

140CPU67160C

確保唯一連接到以太網的設備是PC運行OS加載器和CPU、NOE或CRP模塊，CPU必須處于停止模式，NOE和CRP模塊必須沒有TCP流量。

運行操作系統加載程序的PC和CPU之間的物理連接或者可以執行以太網通信模塊：

通過在PC和以太網通信模塊

通過連接PC和CPU或以太網通信模塊

通過集線器連接兩根“非交叉”以太網電纜。

在這兩種情況下，使用FTP協議，并且只有以太網協處理器可以通過這種方式更新CPU的固件。

應用

過程控制基礎設施

安全

行業

Modicon Quantum自動化平臺專門設計用于工業中的關鍵應用，如：

石化水泥

能源

冶金

隧道

水處理

機場

140CPU67160C

SCHNEIDER 140CPU67160C Communication bus module

SCHNEIDER 140CPU67160C Communication bus module Product details

Manufacturing: In the manufacturing industry, the communication bus module can be used to integrate and control various automation equipment and systems, such as robots, production lines, sensors, actuators, etc. It can communicate with other devices to achieve data transmission and coordinated operations, improving production efficiency and quality.

Industrial control system: The communication bus module can be used with other control equipment and instruments to realize the monitoring and control of industrial processes. It can receive and send data to achieve communication with PLC (Programmable logic controller), DCS (distributed control system) and other systems to ensure coordinated operation between devices.

Energy Management: In the field of energy management, the communication bus module can be used to integrate energy monitoring and management systems. It can communicate with energy metering meters, power monitoring equipment, etc., to achieve energy data collection, analysis and control, to help optimize energy use and improve energy efficiency.

Building automation: Communication bus modules can be used in building automation systems to integrate and control various equipment and systems in buildings, such as lighting, air conditioning, security, fire protection, etc. It can communicate with different building equipment, achieve centralized control and monitoring, and improve the operating efficiency and comfort of the building.
Ethernet firmware

Although Ethernet allows remote access to the upload/download process over the network, we strongly recommend installing only by the CPU, power supply, and rack. Once complete, configure the PLC system address configuration using an empty program that contains only IP. Note that the Ethernet module must be located on the same logical Ethernet network as the PC with the operating system loader (for both IP addresses, subnet masks, and default gateways must be compatible).

Ensure that the only device connected to Ethernet is the PC running the OS loader and the CPU, NOE or CRP modules, the CPU must be in stop mode and the NOE and CRP modules must be free of TCP traffic.

Physical connection between PC and CPU running the operating system loader or Ethernet communication module can be executed:

Communication modules via PC and Ethernet

By connecting PC and CPU or Ethernet communication module

Connect two “non-crossed” Ethernet cables through the hub.

In both cases, the FTP protocol is used, and only the Ethernet coprocessor can update the firmware of the CPU in this way.

Apply

Process control infrastructure

secure

profession

The Modicon Quantum automation platform is specifically designed for critical applications in industry, such as:

Petrochemical cement

Source of energy

metallurgy

tunnel

Water treatment

aerodrome
