SR469-P5-HI-A20-E提供70-265伏交流電，90-300伏直流電控制電源。該設備有一個增強型前面板。但是，如果您需要一個可以在惡劣環境中使用的裝置，請參考我們的SR469P5-HI-A20-E-H清單，除了一個額外的惡劣環境保形涂層外，它在各方面都與該裝置相似
SR469-P5-HI-A20-E有一個精心設計的前面板，易于使用該面板包括一個RS-232程序端口接口，波特率為9600，可編程高達19200波特。這個面板有一個抽出式把手，可以密封，以防止任何未經授權的移動。前面板有一個大液晶顯示器，可顯示40個字符。用戶可以通過該顯示器在本地看到跳閘或報警等診斷信息。此外，面板還有電機和輸出狀態指示器、裝置指示器、數字鍵盤、控制和編程鍵，包括復位、退出和菜單按鈕，以及允許用戶更改設定值的數值鍵

469-P5-HI-A20-E

469-P5-HI-A20-E GE 電機管理繼電器
帶5 A相位CT次級線圈的多線繼電器，90-300VDC 70-265VAC，48至62Hz
469-P5-HI-A20-E GE 電機管理繼電器
模擬輸出 四(4)個4至20毫安模擬輸出
控制權 90至300伏DC；48至62赫茲時70至265伏交流電
顯示 增強型顯示屏，更大的液晶屏
惡劣環境 鈉
制造商 美國通用電氣公司
相電流 5 A相CT次級線圈
469-P5-HI-A20-E GE 電機管理繼電器
關于469-P5-HI-A20-E的常見問題
有哪些更常見的診斷信息可以幫助用戶對469-P5-HI-A20-E繼電器進行故障診斷，這些信息是如何顯示的？
故障代碼、跳閘、警報等。顯示在469-P5-HI-A20-E屏幕上的信息總是按重要性順序排列。用戶可以使用下一個鍵來滾動消息并閱讀多個顯示的各種故障。如果469-P5-HI-A20-E在給定時間內沒有顯示故障代碼或報警，信息LED指示燈將一直亮著。用戶在使用469-P5-HI-A20-E時可能會遇到的一些更常見的警報有:拒絕輸入密碼、按下此處的鍵無效以及數據輸入不完整。所有這些值都很容易確定。更多信息請參考Multilin 469系列說明書和安裝手冊。
469-P5-HI-A20-E CT的菜單導航難導航嗎？在哪里可以找到有幫助的信息？
手冊中的第1章:開始使用提供了469-P5-HI-A20-E的菜單導航參數的簡單易用的細目分類。諸如電機和系統狀態、計量數據和電機學習數據等菜單都可以選擇，并允許用戶更具體地查看出現在任何一個標題下的讀數。這些分類很容易理解，也很方便用戶使用。
AX Control有賣469-P5-HI-A20-E嗎？有哪些購買選擇？
469-P5-HI-A20-E是我們積極儲備的產品，我們盡最大努力保持貨架上的新品和翻新品。我們還為需要評估和維修的繼電器有缺陷的客戶提供統一報價維修選項。所有產品在購買或維修后返回時都提供保修。

469-P5-HI-A20-E

The SR469-P5-HI-A20-E provides 70-265 volts AC and 90-300 volts DC control power. The device has an enhanced front panel. However, if you need a unit that can be used in harsh environments, please refer to our SR469P5-HI-A20-E-H listing, which is similar to this unit in every respect except for an additional harsh environment conformal coating
The SR469-P5-HI-A20-E has a well-designed front panel for ease of use that includes an RS-232 program port interface with a baud rate of 9600 and programmable up to 19,200 baud. This panel has a pull-out handle that can be sealed to prevent any unauthorized movement. The front panel has a large LCD display that can display 40 characters. Users can see diagnostic information such as tripping or alarm locally through the display. In addition, the panel has motor and output status indicators, device indicators, numeric keypads, control and programming keys, including reset, exit and menu buttons, and numeric keys that allow the user to change set values
469-P5-HI-A20-E GE Motor management relay
Multiwire relay with 5 A phase CT secondary coil, 90-300VDC 70-265VAC, 48 to 62Hz
469-P5-HI-A20-E GE Motor management relay
Analog output Four (4) analog outputs from 4 to 20 mA
Control 90 to 300 volts DC; 70 to 265 volts AC at 48 to 62 Hz
Display enhanced display, larger LCD screen
Harsh sodium
Manufacturer General Electric
Phase current 5 A phase CT secondary coil
469-P5-HI-A20-E GE Motor management relay
Frequently Asked Questions about 469-P5-HI-A20-E
What are some of the more common diagnostic information that can help a user fault diagnose the 469-P5-HI-A20-E relay, and how is this information displayed?
Fault codes, trips, alarms, etc. The information displayed on the 469-P5-HI-A20-E screen is always in order of importance. The user can use the next key to scroll through messages and read the various faults on multiple displays. If the 469-P5-HI-A20-E does not display a fault code or alarm within a given time, the information LED will remain on. Some of the more common alarms that users may experience when using 469-P5-HI-A20-E are: Password denied, invalid keys pressed here, and incomplete data entry. All of these values are easy to determine. Refer to the Multilin 469 Series manual and installation manual for more information.
469-P5-HI-A20-E Is the menu navigation for CT difficult to navigate? Where can I find helpful information?
The manual in Chapter 1: Getting Started provides an easy-to-use breakdown of the menu navigation parameters of 469-P5-HI-A20-E. Menus such as motor and system status, metering data, and motor learning data are selectable and allow the user to view the readings that appear under any one heading more specifically. These categories are easy to understand and easy for users to use.
Does AX Control carry 469-P5-HI-A20-E? What are the buying options?
469-P5-HI-A20-E is a product that we actively stock and we do our best to keep new and restocked on the shelves. We also offer a flat quote repair option for customers who need to evaluate and repair defective relays. All products are covered by warranty upon return after purchase or repair.
