1756-L73? A-B羅克韋爾 處理器模塊能夠連接128，000個輸入和輸出信號以及4000個模擬輸入和輸出信號。它可以實現本地I/0配置，其中I/0模塊安裝在安裝控制器的同一機箱內，或者實現分布式1/0拓?fù)?，其中擴展1/0安裝在遠離處理器的位置，并通過擴展通信總線提供1/0.該控制器支持以太網I/P、DeviceNet、 ControlNet、Synchlink以及傳統通信協議，如Data Highway Plus (DH+)、Remote l/0RI0)和第三方協議，它也可以被配置成與網關和協議轉換器通信。同樣，該控制器與何Allen-Bradley encompose partnercontrollogix模塊兼容。
1756-L73? A-B羅克韋爾 處理器模塊該控制器還帶有集成運動，因?yàn)樗С諷ERCOS接口、模擬運動傳感器和以大網I/P上的運動控制。在對該控制器進行編程時，適用的編程語言包括繼電器梯形圖、結構化文本、功能框圖和順序功能圖。

1756-L73

該控制器能夠處理32個控制器任務，每個任務100個程序，而事件任務接受所有事件觸發。該控制器配有8MB用戶內存和0.98MB的I/O內存。它還配備了能量存儲技術，無需使用電池來保存易失性存儲器中的內容。
1756-L73? A-B羅克韋爾 處理器模塊可以使用高達8 MB的用戶內存和0.98 MB的輸入/輸出內存。此外，它總共有128，000個數字/0，最多有4000個模擬1/0。在1.2V DC下所需的電流消耗是5 mA，在5.1V DC下需要800 mA的電流消耗。1756-L73的功耗為2.5 W，散熱為8.5BTU/小時。在基本絕緣條件下，隔離電壓持續為30V，在500V交流電下測試60秒。使用USB 2.0，全速可以達到12 Mbps。約重0.25千克，1槽寬，開放式外殼
該模塊在1756機箱系列的任何插槽中都是基于機箱的。1756-L73控制器的電源要求是標準的1756電源。它的接線類別是USB端口上的3。1756-L73控制器的工作溫度為0-60攝氏度。它的非工作溫度是-40-85攝氏度。攝氏度。它能工作的最高環境溫度是60。5-95%非冷凝相對濕度，其工作振動為10 – 500 H，為2 g，工作沖擊為30 g，非工作沖擊為50 g，安裝SD卡時可達459

1756-L73

The 1756-L73 A-B Rockwell processor module is capable of connecting 128,000 input and output signals and 4,000 analog input and output signals. It can implement a local I/0 configuration, where the I/0 module is installed in the same chassis where the controller is installed, or a distributed 1/0 topology, where the extended 1/0 is installed away from the processor and provided via an extended communication bus. The controller supports Ethernet I/P, DeviceNet, ControlNet, Synchlink, as well as traditional communication protocols such as Data Highway Plus (DH+), Remote l/0RI0, and third-party protocols, and it can also be configured to communicate with gateways and protocol converters. Similarly, the controller is compatible with the Ho Allen-Bradley encompose partnercontrollogix module.
1756-L73 A-B Rockwell Processor Module The controller also comes with integrated motion as it supports SERCOS interfaces, analog motion sensors and motion control on large network I/P. When programming the controller, the applicable programming languages include relay ladder diagram, structured text, function block diagram and sequence function diagram.
The controller is capable of handling 32 controller tasks with 100 programs per task, while the event task accepts all event triggers. The controller comes with 8MB of user memory and 0.98MB of I/O memory. It is also equipped with energy storage technology that eliminates the need to use batteries to preserve the contents of volatile memory.
The 1756-L73 A-B Rockwell processor module can use up to 8 MB of user memory and 0.98 MB of input/output memory. In addition, it has a total of 128,000 digital / 0s and a maximum of 4,000 analog 1/0s. The required current consumption is 5 mA at 1.2V DC and 800 mA at 5.1V DC. The 1756-L73 has a power consumption of 2.5 W and a heat dissipation of 8.5BTU/ hour. Under basic insulation conditions, the isolation voltage is sustained at 30V and tested at 500V AC for 60 seconds. With USB 2.0, full speed can reach 12 Mbps. Weighs about 0.25 kg, 1 slot wide, open housing
The module is chassis based in any slot of the 1756 chassis series. The power requirements for the 1756-L73 controller are the standard 1756 power supply. Its wiring category is 3 on the USB port. The 1756-L73 controller operates at 0-60 degrees Celsius. Its non-operating temperature is -40-85 degrees Celsius. Degrees Celsius. The maximum ambient temperature at which it can operate is 60. 5-95% non-condensing relative humidity, its working vibration is 10-500 H, is 2 g, working shock is 30 g, non-working shock is 50 g, up to 459 when SD card is installed

1756-L72S
