目錄號為2711-K6C5的PanelView標準操作員終端是來自2711-K6C5 Allen- Bradley 交流電源。該操作員終端更普遍地被稱為人機界面(HMI),其主要目的是通過嵌入HMI內的特征組合，為過程操作員提供實時監控和過程界面。過程可視化通過5英寸彩色圖形顯示器實現，其中可以實現帶有彩色編碼信息的動畫。這個彩色屏幕具有115x 86毫米(4.54X3.4英寸)的功能顯示區域。)屏幕分辨率為320×234像素。屏幕配有內部背光，可現場更換，預計工作時間可達50，000小時
2711-K6C5 Allen- Bradley 交流電源由十(10)個功能鍵、導航和數字鍵組成的嵌入式鍵盤提供操作員控制和界面。每個鍵執行單獨的功能，功能鍵能夠接受本地和全局分配。這些鍵預計可啟動100萬次，并可與功能鍵圖例插件一起安裝
2711-K6C5具有DH485通信端口，可與艾倫-布拉德利的不同可編程邏輯控制器(PLC)產品兼容，如SLC 500、MicroLogix.CompactLogix和ControlLogix處理器。它還兼容第三方控制器和設備，實現過程可視化和集中監控

2711-K6C5

2711-K6C5是小型機器和過程的理想選擇。它有一個內置的240KB非易失性存儲器和190KB運行時應用程序存儲器。它的額定電源輸入范圍為85-264伏交流電，頻率為47-63赫茲。
2711-K6C5 Allen- Bradley 交流電源這臺PV 600有一個生動的5英寸。彩色顯示器。用戶能夠使用鍵盤控制HMI來輸入信息和數據.
藝裝置使用85-264伏交流電供電。該單元具有以下240 KB非易失性內存和190KB運行時內存，2711-K6C5 PanelView的可更背光為2711-NL3(適用于A系列和B系列設備)和2711-NL5(適用于C系列設備)。
RS-232(DH-485協議)終端使用DH-485協議連接到Micrologx和SLC 500控制器。點對點配置對高優先級數據使用單獨的連接。他們還可以使用AIC+模塊連接到DH-485網絡
這一過程也可以通過RS-232打印機端口、標準RS-232/DH-85端口或PC存儲卡(如2711-NM232)來完成

2711-K6C5

The PanelView Standard operator terminal with catalog number 2711-K6C5 is from the 2711-K6C5 Allen-Bradley AC power supply. More commonly known as the Human Machine Interface (HMI), the main purpose of this operator terminal is to provide real-time monitoring and process interface to process operators through a combination of features embedded within the HMI. Process visualization is achieved through a 5-inch color graphic display, where animations with color-coded information can be implemented. This color screen has a 115x 86 mm (4.54X3.4 inches) functional display area.) The screen resolution is 320×234 pixels. The screen has an internal backlight, can be replaced on site and has an estimated operating time of 50,000 hours
2711-K6C5 Allen-Bradley AC Power Supply An embedded keyboard consisting of ten (10) function keys, navigation, and numeric keys provides operator control and interface. Each key performs a separate function, and function keys can accept both local and global assignments. These keys are expected to launch 1 million times and can be installed with the function key legend plug-in
The 2711-K6C5 features a DH485 communication port and is compatible with different Allen Bradley Programmable Logic controller (PLC) products, such as the SLC 500, MicroLogix.CompactLogix, and ControlLogix processors. It is also compatible with third-party controllers and devices, enabling process visualization and centralized monitoring
The 2711-K6C5 is ideal for small machines and processes. It has a built-in 240KB non-volatile memory and 190KB run-time application memory. It has a rated power input range of 85-264 volts AC and a frequency of 47-63 Hz.
2711-K6C5 Allen-Bradley AC Power Supply This PV 600 has a vivid 5-inch. Color display. Users can use the keyboard to control the HMI to enter information and data.
The installation is powered by 85-264 volts AC. The unit has the following 240 KB of non-volatile memory and 190KB of runtime memory, and the 2711-K6C5 PanelView can be backlit 2711-NL3(for Series A and Series B devices) and 2711-NL5(for Series C devices).
RS-232(DH-485 protocol) terminals use the DH-485 protocol to connect to Micrologx and SLC 500 controllers. A peer-to-peer configuration uses separate connections for high-priority data. They can also connect to DH-485 networks using AIC+ modules
This process can also be done via an RS-232 printer port, a standard RS-232/DH-85 port, or a PC memory card such as 2711-NM232

2711-K6C5
