制造商:Triconex

產品編號:3009

產品類型:增強型主處理器(UMP)模塊

運輸量:10公斤

Tricon控制系統的主要特點

Tricon是一種高容錯的可編程和過程控制技術。

其特點如下:

A.提供三模冗余結構(TMR ),具有三個相同的子電路，每個子電路執行獨立程度的控制。還有一個專用的硬件/軟件架構，用于對輸入和輸出進行“表

能夠忍受惡劣的工業環境。

C.它可以在現場安裝，并組可以在不干擾現場布線的情況下在現場在線安裝和修復模塊級。

D.支持多達1 18個I/O模塊(模擬和數字)和可選通信模塊。通信模塊可以

連接到Modbus主機和從屬設備，或連接到Foxboro和Honeywell分布式控制系統(DCS), 對等網絡中的其他Tricons,以及TCP/IP網絡中的外部主

機。

3009

E.可以支持距離大型機最遠1 2公里的遠程1/O模塊。

F.使用基于Windows NT系統的編程軟件開發和調試控制程序。

G.輸入和輸出模塊中的智能功能可減少主處理器的工作負荷。每個I/O模塊有三個微處理器。輸入模塊的微處理器過濾和修復輸入，并診斷模塊上的

硬件故障。輸出模塊微處理器為輸出數據的表決提供信息，通過輸出端的反饋回路電壓檢查輸出狀態的有效性,并能診斷場線問題。

H.提供全面的在線診斷和修復能力。

1. Tricon啟動和運行時，可以進行日常維護，而不會中斷控制過程。

J.為I/O模塊提供“熱備用”支持，可用于某些無法及時提供服務的緊急情況。

3009

Manufacturer :Triconex

Product Number :3009

Product type: Enhanced Main Processor (UMP) module

Transport capacity :10 kg

Key features of the Tricon control system

Tricon is a highly fault-tolerant programmable and process control technology.

Its characteristics are as follows:

A. Provide a three-mode redundant structure (TMR) with three identical subcircuits, each performing an independent degree of control. There is also a dedicated hardware/software architecture for tabulating inputs and outputs

Able to endure harsh industrial environments.

C. It can be installed in the field, and the group can be installed and repaired online in the field without interfering with the field wiring.

D. Supports up to 18 I/O modules (analog and digital) and optional communication modules. Communication module can

Connect to Modbus hosts and slave devices, or to Foxboro and Honeywell Distributed Control Systems (DCS), other Tricons in peer-to-peer networks, and external masters in TCP/IP networks

Airplane.

E. It can support remote 1/O modules up to 12 km away from the mainframe.

F. Develop and debug control programs using programming software based on Windows NT systems.

G. Intelligent functions in the input and output modules reduce the workload of the main processor. Each I/O module has three microprocessors. The input module’s microprocessor filters and repairs the input, and diagnoses the module on it

The hardware is faulty. The output module microprocessor provides information for the voting of the output data, checks the validity of the output state by the feedback loop voltage at the output, and can diagnose field line problems.

H. Provide comprehensive online diagnostic and repair capabilities.

1. When Tricon is up and running, routine maintenance can be carried out without interrupting the control process.

J. Provide “hot backup” support for I/O modules, which can be used in certain emergency situations where service cannot be provided in time.

3009
