制造商:Triconex
產品編號:3351
產品類型:模擬輸入模塊
標稱輸入電流:4-20毫安
點數:32，普通
工作電流范圍:2-22毫安DC
輸入帶寬(3dB): 16赫茲
源阻抗:180?
重量:1.5公斤
運輸重量:3公斤
Tricon控制系統的主要特點
Tricon是一種高容錯的可編程和過程控制技術。
其特點如下:
A.提供三模幾余結構(TMR ),具有三個相同的子電路，每個子電路執行獨立程度的控制。還有一個專用的硬件/軟件架構，用于對輸入和輸出進行“表決”

3351

能夠忍受惡劣的工業環境.C.它可以在現場安裝，并且可以在不干擾現場布線的情況下在現場在線安裝和修復模塊級。D.支持多達118個I/0模塊(模擬和數字)和可選通信模塊。通信模塊可以連接到Modbus主機和從屬設備，或連接到Foxboro和Honeywell分布式控制系統DCS)，對等網絡中的其他Tricons，以及TCP/IP網絡中的外部主機。
E.可以支持距離大型機最遠12公里的遠程I/O模塊。F.使用基于Windows NT系統的編程軟件開發和調試控制程序。G.輸入和輸出模塊中的智能功能可減少主處理器的工作負荷。每個/0模塊有三個微處理器。輸入模塊的微處理器過濾和修復輸入，并診斷模塊上的硬件故障。輸出模塊微處理器為輸出數據的表決提供信息，通過輸出端的反饋回路電壓檢查輸出狀態的有效性，并能診斷場線問題。
H.提供全面的在線診斷和修復能力。
Tricon啟動和運行時，可以進行日常維護，而不會中斷控制過程J.為I/O模塊提供“熱備用”支持，可用于某些無法及時提供服務的緊急情況。

3351

3351

Manufacturer :Triconex
Product Number :3351
Product type: Analog input module
Nominal input current :4-20 MA
Points :32, normal
Working current range :2-22 mA DC
Input bandwidth (3dB): 16 Hz
Source impedance :180?
Weight :1.5 kg
Shipping weight :3 kg
Key features of the Tricon control system
Tricon is a highly fault-tolerant programmable and process control technology.
Its characteristics are as follows:
A. Provide a three-mode multi-remainder structure (TMR) with three identical subcircuits, each performing an independent degree of control. There is also a dedicated hardware/software architecture for “voting” on inputs and outputs
Able to endure harsh industrial environments. C. It can be installed in the field, and module levels can be installed and repaired online in the field without interfering with the field wiring. D. Supports up to 118 I/0 modules (analog and digital) and optional communication modules. Communication modules can be connected to Modbus hosts and slave devices, or to Foxboro and Honeywell Distributed Control System DCS), other Tricons in peer-to-peer networks, and external hosts in TCP/IP networks.
E. Can support remote I/O modules up to 12 km from the mainframe. F. Develop and debug control programs using programming software based on Windows NT systems. G. Intelligent functions in the input and output modules reduce the workload of the main processor. Each /0 module has three microprocessors. The input module’s microprocessor filters and repairs the input and diagnoses hardware failures on the module. The output module microprocessor provides information for the voting of the output data, checks the validity of the output state by the feedback loop voltage at the output, and can diagnose field line problems.
H. Provide comprehensive online diagnostic and repair capabilities.
When Tricon is up and running, routine maintenance can be performed without interrupting the control process. Provides “hot standby” support for I/O modules, which can be used in certain emergency situations where service cannot be provided in time.
