3401? TRICONEX 控制器卡件主要負責對域內系統數據的集中管理和監視，包括報警、日志、事故追憶等事件的捕捉和記錄管理，并為域內其它各站的數據請求（包括實時數據、事件信息和歷史記錄）提供服務和為其它域的數據請求提供服務。運行系統以系統服務器為中心，完成所有功能。系統服務器還提供二次數據處理和歷史數據管理和存檔功能。

3401? TRICONEX 控制器卡件是DCS系統實現數據采集和過程控制的重要站點，主要完成數據采集、工程單位變換、控制算法處理、輸出控制、通過系統網絡將數據和診斷結果傳送到系統服務器等功能。

3401

3401? TRICONEX 控制器卡件由主控單元、智能I/O單元、電源單元和專用機柜四部分組成，在主控單元和智能I/O單元上，分別固化了實時控制軟件和I/O單元運行軟件?，F(xiàn)場控制站內部采用了分布式的結構，與系統網絡相連接的是現場控制站的主控單元，可冗余配置。主控單元通過控制網絡（CNET）與各個智能I/O單元實現連接。

3401

3401 TRICONEX controller card is mainly responsible for the centralized management and monitoring of system data in the domain, including the capture and record management of alarms, logs, accident recall and other events, and provides services for data requests (including real-time data, event information and history records) of other stations in the domain and provides services for data requests in other domains. The running system takes the system server as the center to complete all functions. The system server also provides secondary data processing and historical data management and archiving functions.

3401 TRICONEX controller card is an important site for DCS system to achieve data acquisition and process control, mainly to complete data acquisition, engineering unit transformation, control algorithm processing, output control, data and diagnostic results transmitted to the system server through the system network.

The 3401 TRICONEX controller card consists of a main control unit, an intelligent I/O unit, a power supply unit and a dedicated cabinet. On the main control unit and intelligent I/O unit, the real-time control software and I/O unit operation software are cured respectively. The field control station adopts the distributed structure, and the main control unit of the field control station is connected with the system network, which can be configured redundantly. The main control unit is connected to each intelligent I/O unit via a control network (CNET).

3401
