TrustedTM TMR廣展接口模塊位于TrustedTM控制框和提供控制機箱模塊間總線(MB)和控制器之間的”主”接口擴張器總線，擴展器總線允許使用UTP實現多個機箱系統電纜連接，同時保持容錯，高帶寬IMB能力。模塊為擴展器總線、模塊本身和IMB提供故障遏制控制框確保這些潛在故的影響是局部和系統的可用性最大化。該模塊具有HIFT TMR架構的容錯功能。全面的診斷、監控和測試提供了快速的故障識別。雙機熱備，模塊備用支持插槽配置，允許自動和手動修復策略
TRICONEX產品具有良好的靈活性，可根據客戶的需求進行定制和配置。它們支持多種通信接口和協議，以便與其他設備和系統進行無縫集成。

3481

TRICONEX產品具備良好的可擴展性，可以根據系統需求進行模塊化擴展。用戶可以根據需要添加額外的輸入輸出模塊、通信模塊或其他功能模塊，以滿足系統的擴展和升級需求。
TRICONEX產品具備優秀的性能，包括高速的數據采集和處理能力、精確的控制算法、快速的響應時間等。這使得其產品能夠滿足高要求的工業自動化和控制應用。
特性
三重模塊元余(TMR)，容錯(3-2-0)操作
硬件實現容錯(HIFT架構
專用的硬件和軟件測試制度，提供非常快速的故障識別和響應時間
自動故障處理，無騷擾報警
熱更換
顯示模塊運行狀況和狀態的前面板指示燈。T2V認證的IEC 61508 SIL 3
貨號(面向市場編號) : T3481
產品設計: TrustedTM TMR擴展器接口
制造商: ICS TRIPLEX
原產地 : 美國
標準交貨時間出廠: 現貨

3481

The TrustedTM TMR Wide-Spread Interface module sits on the TrustedTM controller enclosure and provides the “master” interface expander bus between the control Enclosure Module (MB) and the controller. The expander bus allows multiple chassis system cable connections to be achieved using UTP while maintaining fault-tolerant, high-bandwidth IMB capability. The module provides a fail-safe controller enclosure for the extender bus, the module itself, and the IMB to ensure that these potential impacts are local and system availability is maximized. The module has fault tolerance of the HIFT TMR architecture. Comprehensive diagnostics, monitoring and testing provide rapid fault identification. Dual-system hot backup, module backup supports slot configuration, allowing automatic and manual repair policies
TRICONEX products are flexible and can be customized and configured according to customer needs. They support multiple communication interfaces and protocols for seamless integration with other devices and systems.
peculiarity
Triple modular residue (TMR), fault-tolerant (3-2-0) operation
The hardware implements a fault-tolerant (HIFT) architecture
Dedicated hardware and software testing regimes provide very fast fault identification and response times
Automatic fault handling, no disturbance alarm
Hot change
Front panel indicators that show module health and status. T2V certified IEC 61508 SIL 3
Item number (market oriented number) : T3481
Product Design: TrustedTM TMR extender interface
Manufacturer: ICS TRIPLEX
Country of Origin: USA
Standard delivery time Factory: From stock
