16通道繼電器模塊需要3500機架配置，版本3.3或更高版本。

-16通道繼電器模塊需要：3500數據采集軟件，版本2.40或更高版本。

-16通道繼電器模塊需要：3500數據顯示軟件版本 1.40或更高

16通道繼電器模塊 3500/33 本特利3500檢測系統模塊

繼電器模塊組態事項

3500/33

●在組態繼電器模塊之前，先將監測器模塊加到框架組態上。

●只將要用到的繼電器塊通道激活。

●在報警驅動邏輯器中，只有監測器模塊可能被用到。

●只有三重模冗余組的第一個監測器模塊，需要加到報警驅動邏輯器上。

●如果一條通道產生一個報警，而這個報瞥是與(AND)運算器的一部分，并且該通道被旁路，則被旁路的通道運算值為真。由于旁路，報警不會被抑制。

●如果一條通道產生一個報警，而這個報警是或(OR) 運算器的一 部分，并且該通道被旁路，則被旁路的通道運算值為假。

●對于一個四通道標準繼電器，對整個繼電器組態來說，產生的指令不會超過60條。能被繼電器所接收的指令數，也依賴于繼電器程序語言的版本。高于等于(≥) 2. 0版的繼電器程序語言,將能接收更加復雜的繼電器報警驅動邏輯方程。在發送之前，程序語言的版本將被檢查，同時將決定繼電器是否能接收指令設置。
靈敏度3.94mV/mm/s (1mv /in/s)±。
頻率
響應
4.5 Hz至5 kHz (27cpm至3)
kcpm)±3.dB。
6.Hz至2.5 kHz (36cpm至15)
kcpm)±.9 dB。
溫度
靈敏度
-到+7.
工作溫度范圍
速度范圍127mm /s (5in/s)峰值。

3500/33

The 16-channel relay module requires 3500 rack configurations, version 3.3 or later.

-16 channel relay module requires: 3500 data acquisition software, version 2.40 or later.

-16 channel relay module required: 3500 data display software version 1.40 or higher

16-channel relay module 3500/33 Bentley 3500 inspection system module

Relay module configuration matters

● Add the monitor module to the frame configuration before configuring the relay module.

● Only the relay block channel that will be used is activated.

● In the alarm driver logic, only the monitor module may be used.

● The first monitor module with only triple mode redundancy needs to be added to the alarm driver logic.

If a channel generates an alarm that is part of the AND (AND) operator and the channel is bypassed, then the bypassed channel operation is true. Because of the bypass, the alarm is not suppressed.

● If a channel generates an alarm that is part of an OR (OR) operator and the channel is bypassed, the bypassed channel operation is false.

● For a four-channel standard relay, no more than 60 instructions are generated for the entire relay configuration. The number of instructions that can be received by the relay also depends on the version of the relay programming language. A relay programming language greater than or equal to (≥) version 2.0 will be able to accept more complex relay alarm drive logic equations. Before sending, the version of the program language will be checked and it will be determined whether the relay can receive the instruction Settings.
Sensitivity 3.94mV/mm/s (1mv /in/s)±.
frequency
respond
4.5Hz to 5 kHz (27cpm to 3)
kcpm)±3.dB.
6.Hz to 2.5 kHz (36cpm to 15)
kcpm)±.9 dB.
temperature
sensitivity
– To +7.
Operating temperature range
Speed range 127mm /s (5in/s) peak.

3500/33
