Tricon 3625C1支持兩種基本類型的數字輸入模塊：TMR和單個。以下段落介紹了數字輸入模塊的一般情況，隨后介紹了TMR和單個模塊的具體情況。每個數字輸入模塊都包含三個相同通道（A、B和C）的電路。

盡管通道位于同一模塊上，但它們彼此完全隔離并獨立運行。一個通道上的故障不能傳遞到另一個通道。此外，每個通道都包含一個稱為I/O通信處理器的8位微處理器，該微處理器處理與其相應的主處理器的通信。

三個輸入通道中的每個通道異步測量來自輸入端接模塊上每個點的輸入信號，確定輸入信號的相應狀態，并將值分別放入輸入表A、B和C中。位于相應主處理器模塊上的I/O通信處理器通過I/O總線定期詢問每個輸入表。例如，主處理器A通過I/O總線A詢問輸入表A。在TMR數字輸入模塊上，所有關鍵信號路徑都是100%的三倍，以保證安全性和最大可用性。每個通道獨立調節信號，并在現場和Tricon之間提供隔離。（64點高密度數字輸入模塊是一個例外，它沒有通道到通道隔離。）

3625C1

英維思運營管理（Invensys Operations Management）是英維思集團的一個業務部門，是為制造行業和基礎設施建設行業提供自動化和信息技術、系統、軟件解決方案、服務和咨詢業務的提供商。英維思運營管理總部設在美國德克薩斯州的休斯敦，其解決方案被遍布的超過4萬個用戶應用于全世界20多萬家工廠和機構。

英維思Invensys 供應Triconex 基本數字量輸入端子 9750-310 (24VDV basic32pts)

XiaMen XingRuiDa supply英維思Invensys 供應Triconex 基本數字量輸入端子 9750-310 (24VDV basic32pts)
Triconex 版本 9-10 系統
數字量輸出模塊3603B用的終端面板9251-210
模擬量輸入模塊3806E用的終端面板9863-710
數字量輸入終端面板
16點通用數字輸入端子
9561-810 （115V Commoned 16 pts)
9562-810 (48V Commoned 19 pts)
9563-810 (24V Commoned 16 pts)
9563-910 (24V Commoned resistor protected16pts)
32點通用數字輸入端子
9565-810 （48VDCCommoned 32 pts)
9566-710 (24VDCCommoned 32 pts)

3625C1

The Tricon 3625C1 supports two basic types of digital input modules: TMR and single. The following paragraphs describe the digital input modules in general, followed by the details of TMR and individual modules. Each digital input module contains three circuits with the same channels (A, B, and C).

Although the channels are located on the same module, they are completely isolated from each other and operate independently. A fault on one channel cannot be transmitted to another channel. In addition, each channel contains an 8-bit microprocessor called an I/O communication processor, which handles the communication with its corresponding main processor.

Each of the three input channels asynchronously measures the input signal from each point on the input terminal module, determines the corresponding state of the input signal, and places the values into input tables A, B, and C, respectively. The I/O communication processor located on the corresponding main processor module periodically queries each input table through the I/O bus. For example, the main processor A queries the input table A through the I/O bus A. On the TMR digital input module, all critical signal paths are tripled to 100% for security and maximum availability. Each channel regulates the signal independently and provides isolation between the field and Tricon. (An exception is the 64-point high-density digital input module, which does not have channel-to-channel isolation.)
Invensys Operations Management, a business unit of the Invensys Group, is a provider of automation and information technology, systems, software solutions, services and consulting to the manufacturing and infrastructure industries. Invensys Operations Management is headquartered in Houston, Texas, USA, and its solutions are used by more than 40,000 users in more than 200,000 plants and facilities worldwide.

Invensys supplies Triconex Basic Digital Input Terminals 9750-310 (24VDV basic32pts)

XiaMen XingRuiDa supply Invensys Triconex Basic Digital Input Terminal 9750-310 (24VDV basic32pts)
Triconex version 9-10 system
Terminal panel 9251-210 for digital output module 3603B
Terminal panel 9863-710 for analog input module 3806E
Digital quantity input terminal panel
16-point universal digital input terminals
9561-810 (115V Commoned 16 pts)
9562-810 (48V Commoned 19 pts)
9563-810 (24V Commoned 16 pts)
9563-910 (24V Commoned resistor protected16pts)
32 point universal digital input terminals
9565-810 (48VDCCommoned 32 pts)
9566-710 (24VDCCommoned 32 pts)

3625C1
