功能 / 技術規格
整裝式、獨立安裝的監測器
連續監測和保護，適合于自動停機應用
4通道振動輸入（2線和3線速度和加速度傳感器，以及Bently Nevada電渦流傳感器）
每個通道最多4個變量，具有獨立積分和濾波控制
某些變量具有多達八極點的濾波
24位A/D轉換器，25 kHz 帶寬
4通道溫度輸入（E、J、K和 T 型熱電偶）
2級報警 – 警告（ALERT）和危險（DANGER）
6個可組態的繼電器，帶有表決邏輯
緩沖傳感器輸出-4個監測器輸出，1個顯示裝置輸出
4個可組態的4-20 mA記錄儀輸出
單獨應用的組態軟件
接收18至36Vdc電源；提供一個110/220Vac外部電源
可通過DIN導軌支架或安裝壁板進行安裝
結構緊湊 – 其尺寸為（英寸）：
– 監測器：7.75 x 5.88 x 2.93
– 顯示裝置：7.75 x 5.03 x 1.29
– 監測器帶顯示裝置：7.75 x 5.88 x 3.85
可選的玻璃纖維護罩，或鋼制防護門（用于面板安裝），以滿足環境防護安裝要求和IP65
即將批準的危險地區許可，包括CSA（1級2區 -雖然監測器不能安裝于1類地區，但它通過絕緣裝置和隔柵支持安裝于1區的傳感器）、ATEX
（2區）、CE和GOST（IEC Ex)
Bently 1900/65A 通用設備監控器旨在持續監控和保護各種應用和行業中使用的設備。該監視器的低成本使其成為通用機器和流程的理想解決方案，可受益于持續監控和保護。

190065A

1900/65A 提供四個傳感器輸入和四個溫度輸入。軟件可以配置每個傳感器輸入以支持 2 線和 3 線加速度計、速度傳感器或接近傳感器。每個溫度輸入支持 E、J、K 和 T 型熱電偶以及 2 線或 3 線 RTD。

1900/65A 提供六個繼電器輸出、四個 4-20 mA 記錄儀輸出和一個專用緩沖輸出。用戶可以使用 1900 配置軟件根據任何通道或通道組合的正常、警報和危險狀態將繼電器觸點配置為打開或關閉，并在任何記錄儀輸出上提供來自任何通道的任何變量的數據。專用緩沖器輸出可為每個傳感器輸入提供信號。

用戶通過使用筆記本電腦或 PC 上運行的軟件來定義顯示器操作和 Modbus 網關寄存器映射，創建配置文件并通過內置以太網連接將文件下載到顯示器。1900/65A 將配置信息永久存儲在非易失性存儲器中，并可以將此信息上傳到 PC 進行更改。

1900/65A 支持可選的顯示屏/鍵盤來查看通道信息或進行較小的配置更改。這使得 1900/65A 能夠作為獨立套件運行。如果需要，用戶可以將顯示器安裝在距離顯示器模塊 75 米（250 英尺）的地方。

190065A

Functional/technical specifications
Integrated, individually mounted monitor
Continuous monitoring and protection for automatic shutdown applications
4-channel vibration input (2-wire and 3-wire speed and acceleration sensors, as well as Bently Nevada eddy current sensor)
Each channel has up to 4 variables with independent integration and filtering control
Some variables have filters of up to eight poles
24-bit A/D converter, 25 kHz bandwidth
4 channel temperature input (E, J, K and T thermocouples)
Level 2 alarm – ALERT and DANGER
6 configurable relays with voting logic
Buffer sensor output -4 monitor output, 1 display output
Four configurable 4-20 mA recorder outputs
Configuration software for separate applications
Receive 18 to 36Vdc power supply; A 110/220Vac external power supply is available
It can be installed with DIN rail brackets or mounted siding
Compact – its dimensions are (inches) :
– Monitor: 7.75 x 5.88 x 2.93
– Display device: 7.75 x 5.03 x 1.29
– Monitor with display device: 7.75 x 5.88 x 3.85
Optional fiberglass guard, or steel protective door (for panel mounting) to meet environmental protection installation requirements and IP65
Pending approvals for hazardous areas include CSA (Class 1 Zone 2 – although the monitor cannot be installed in Class 1, it supports sensors installed in Zone 1 through insulation and barriers), ATEX
(Zone 2), CE and GOST (IEC Ex)
The Bently 1900/65A universal device monitor is designed to continuously monitor and protect devices used in a variety of applications and industries. The low cost of this monitor makes it an ideal solution for general-purpose machines and processes that can benefit from continuous monitoring and protection.

The 1900/65A offers four sensor inputs and four temperature inputs. The software can configure each sensor input to support 2-wire and 3-wire accelerometers, speed sensors, or proximity sensors. Each temperature input supports E, J, K, and T thermocouples and 2 – or 3-wire RTDS.

The 1900/65A offers six relay outputs, four 4-20 mA recorder outputs, and a dedicated buffer output. Users can use the 1900 configuration software to configure relay contacts to open or close based on the normal, alarm, and hazardous states of any channel or combination of channels, and to provide data on any variable from any channel on any logger output. A dedicated buffer output provides a signal for each sensor input.

Users define display operations and Modbus gateway register maps by using software running on a laptop or PC, create a configuration file and download the file to the display via a built-in Ethernet connection. The 1900/65A stores configuration information permanently in non-volatile memory and can upload this information to a PC to make changes.

The 1900/65A supports an optional display/keyboard to view channel information or make minor configuration changes. This allows the 1900/65A to operate as a standalone package. If desired, the user can install the display 75 meters (250 feet) away from the display module.
