Product Description :A6500-UM shaft relative vibration mode
The shaft relative vibration mode is used to improve reliability for the most critical rotating equipment in the plant. This function, when combined with the base CS1 A500 ATG monitoring module, forms a complete AP1670 mechanical protection monitoring system. Applications include steam turbines, gas turbines, compressors and water turbines. The main function of shaft relative vibration measurement is to drive the alarm and relay output by comparing the measured parameter with the alarm setting value. To accurately monitor the relative vibration of the shaft and protect the equipment in a reliable manner, the relative vibration of the shaft includes a displacement sensor mounted through the bearing housing or mounted inside the bearing to rotate the shaft or monitor the target mounted on the bearing housing to monitor the rotating shaft The Displacement sensor is a non-contact sensor used to measure the position and movement of the pump. Since the displacement sensor is mounted on the bearing, the monitored parameter is called shaft relative vibration, that is, vibration relative to the bearing housing.
Oil relative vibration is an important measurement index for prediction and protection monitoring on all plain bearing machines. When the weight of the housing is much greater than that of the rotor, and the bearing housing is not expected to vibrate between 0 and normal running speed, relative vibration should be selected. When the bearing housing and rotor masses are close to equal, the absolute shaft vibration measurement is sometimes chosen if the bearing housing is more likely to vibrate and affect the relative shaft vibration reading.
