1、數據緩沖

由于I/O設備的速率較低而CPU和內存的速率卻很高，故在控制器中必須設置一緩沖器。在輸出時，用此緩沖器暫存由主機高速傳來的數據，然后才以I/O設備所具有的速率將緩沖器中的數據傳送給I/O設備；在輸入時，緩沖器則用于暫存從I/O設備送來的數據，待接收到一批數據后，再將緩沖器中的數據高速地傳送給主機。

2、差錯控制

設備控制器還兼管對由I/O設備傳送來的數據進行差錯檢測。若發現傳送中出現了錯誤，通常是將差錯檢測碼置位，并向CPU報告，于是CPU將本次傳送來的數據作廢，并重新進行一次傳送。這樣便可保證數據輸入的正確性。

3、數據交換

這是指實現CPU與控制器之間、控制器與設備之間的數據交換。對于前者，是通過數據總線，由CPU并行地把數據寫入控制器，或從控制器中并行地讀出數據；對于后者，是設備將數據輸入到控制器，或從控制器傳送給設備。為此，在控制器中須設置數據寄存器。

4、狀態說明

標識和報告設備的狀態控制器應記下設備的狀態供CPU了解。例如，僅當該設備處于發送就緒狀態時，CPU才能啟動控制器從設備中讀出數據。為此，在控制器中應設置一狀態寄存器，用其中的每一位來反映設備的某一種狀態。當CPU將該寄存器的內容讀入后，便可了解該設備的狀態。

5、接收和識別命令

CPU可以向控制器發送多種不同的命令，設備控制器應能接收并識別這些命令。為此，在控制器中應具有相應的控制寄存器，用來存放接收的命令和參數，并對所接收的命令進行譯碼。例如，磁盤控制器可以接收CPU發來的Read、Write、Format等15條不同的命令，而且有些命令還帶有參數；相應地，在磁盤控制器中有多個寄存器和命令譯碼器等。

6、地址識別

就像內存中的每一個單元都有一個地址一樣，系統中的每一個設備也都有一個地址，而設備控制器又必須能夠識別它所控制的每個設備的地址。此外，為使CPU能向（或從）寄存器中寫入（或讀出）數據，這些寄存器都應具有唯一的地址。

ABB GFD233A

ABB發明、制造了眾多產品和技術，其中包括全球第一套三相輸電系統、世界上第一臺自冷式變壓器、高壓直流輸電技術和第一臺電動工業機器人，并率先將它們投入商業應用。ABB擁有廣泛的產品線，包括全系列電力變壓器和配電變壓器，高、中、低壓開關柜產品，交流和直流輸配電系統，電力自動化系統，各種測量設備和傳感器，實時控制和優化系統，機器人軟硬件和仿真系統，高效節能的電機和傳動系統，電力質量、轉換和同步系統，保護電力系統安全的熔斷和開關設備。這些產品已廣泛應用于工業、商業、電力和公共事業中。

ABB集團位列全球500強企業（2008年在世界500強排列第256位，2009年位列第230位，2010年位列第237位），2009至2011年銷售額都高達320億美元。并在蘇黎世、斯德哥爾摩和紐約證券交易所上市交易。

安全回路是保護負載或控制對象以及防止操作錯誤或控制失敗而進行連鎖控制的回路。在直接控制負載的同時，安全保護回路還給PLC輸入信號，以便于PLC進行保護處理。安全回路一般考慮以下幾個方面。

（1）短路保護應該在PLC外部輸出回路中裝上熔斷器，進行短路保護。最好在每個負載的回路中都裝上熔斷器。

（2）互鎖與聯鎖措施除在程序中保證電路的互鎖關系，PLC外部接線中還應該采取硬件的互鎖措施，以確保系統安全可靠地運行。

（3）失壓保護與緊急停車措施PLC外部負載的供電線路應具有失壓保護措施，當臨時停電再恢復供電時，不按下“啟動”按鈕PLC的外部負載就不能自行啟動。這種接線方法的另一個作用是，當特殊情況下需要緊急停機時，按下“急?！卑粹o就可以切斷負載電源，同時“急停”信號輸入PLC。

（4）極限保護在有些如提升機類超過限位就有可能產生危險的情況下，設置極限保護，當極限保護動作時直接切斷負載電源，同時將信號輸入

ABB GFD233A

1. Data buffering

Because the I/O device speed is low and the CPU and memory speed is high, a buffer must be set in the controller. When output, the buffer is used to temporarily store the data from the host at high speed, and then the data in the buffer is transmitted to the I/O device at the rate that the I/O device has; During input, the buffer is used to temporarily store the data sent from the I/O device, and after receiving a batch of data, the data in the buffer is transmitted to the host at high speed.

2. Error control

The device controller is also responsible for error detection of data transmitted by the I/O device. If an error is found in the transmission, the error detection code is usually set and reported to the CPU, so the CPU will cancel the data sent this time and retry the transmission. This ensures the correctness of data input.

3. Data exchange

This refers to the realization of data exchange between the CPU and the controller, and between the controller and the device. For the former, through the data bus, the CPU writes the data to the controller in parallel, or reads the data from the controller in parallel; In the latter case, the device inputs data to the controller, or from the controller to the device. For this purpose, a data register must be set up in the controller.

4. Status description

Identifying and reporting the status of the device The controller should record the status of the device for the CPU to understand. For example, the CPU can start the controller to read data from the device only when the device is in the send-ready state. To this end, a status register should be set up in the controller, and each bit of it reflects a certain state of the device. When the CPU reads the contents of the register, it can learn the state of the device.

5. Receive and recognize commands

The CPU can send many different commands to the controller, and the device controller should be able to receive and recognize these commands. Therefore, there should be a corresponding control register in the controller, which is used to store the received commands and parameters, and to decode the received commands. For example, the disk controller can receive 15 different commands from the CPU, such as Read, Write, Format, etc., and some commands have parameters; Accordingly, there are multiple registers and command decoders in the disk controller.

6. Address recognition

Just as every unit in memory has an address, every device in the system has an address, and the device controller must be able to recognize the address of every device it controls. In addition, in order for the CPU to write (or read) data to (or from) registers, these registers should have unique addresses.

ABB invented and manufactured many products and technologies, including the world’s first three-phase power transmission system, the world’s first self-cooling transformer, high-voltage direct current transmission technology and the first electric industrial robot, and pioneered their commercial application. ABB has a wide range of product lines, including a full range of power transformers and distribution transformers, high, medium and low voltage switchgear products, AC and DC transmission and distribution systems, power automation systems, various measuring equipment and sensors, real-time control and optimization systems, robotics hardware and software and simulation systems, energy-efficient motors and drive systems, power quality, conversion and synchronization systems, and other systems. Fusing and switching equipment to protect the safety of power systems. These products have been widely used in industry, commerce, power and public utilities.

ABB is one of the world’s top 500 companies (256th in 2008, 230th in 2009, 237th in 2010), with sales of $32 billion in 2009-2011. It is listed on the Zurich, Stockholm and New York Stock exchanges.

A safety loop is a loop of interlocking control that protects the load or control object and prevents operational errors or control failures. In the direct control of the load at the same time, the safety protection loop to the PLC input signal, in order to facilitate the PLC protection processing. Safety circuits generally consider the following aspects.

(1) Short-circuit protection should be installed in the PLC external output circuit fuse, short-circuit protection. It is best to install a fuse in the circuit of each load.

(2) Interlock and interlock measures in addition to ensuring the interlock relationship of the circuit in the program, the external wiring of the PLC should also take hardware interlock measures to ensure the safe and reliable operation of the system.

(3) Voltage loss protection and emergency shutdown measures PLC external load power supply line should have voltage loss protection measures, when the temporary power failure and then restore power supply, do not press the “start” button PLC external load can not start by itself. Another function of this wiring method is that when emergency shutdown is required under special circumstances, the load power supply can be cut off by pressing the “emergency stop” button, and the “emergency stop” signal is input to the PLC.

(4) Limit protection In some cases such as elevator class exceeding the limit may produce danger, set the limit protection, when the limit protection action directly cut off the load power supply, while the signal input PLC.

ABB GFD233A
