AN-X2-AB-DHRIO網關旨在幫助客戶啟動分階段遷移方法，以更換或升級傳統遠程I/O PLC、HMI、驅動器或Flex I/O適配器。這些解決方案可以通過在初始配置期間選擇相應的操作模式來實現。安-X2-AB-DHRIO有一個內置的網絡服務器，可以顯示診斷數據、配置、上傳配置文件和設置操作模式。
AN-X2-AB-DHRI0是一種通信模塊，由艾倫-布拉德利合作伙伴公司Prosoft Technology制造，這款通信設備小巧緊湊，支持桌面或DIN導軌安裝，它允許現代可編程自動化控制器(PAC)如Allen-Bradley的Contrologix和CompactLogix控制器與采用傳統遠程/0(RI0)和Data HighwayPlus(DH+)通信協議的設備進行通信。
AN-X2-AB-DHRIO有-11個以大網/P通信接口，支持10/10 mps數據傳輸速率，此端將PAC瑞連接到網關，而安X2 a B- DHRI0可用的3針菲尼克斯網絡連接器允許設備的菊花連接，如艾倫-布拉德利的PLCSLC 500、

AN-X2-AB-DHRIO

PanelView、驅動器和Flex /0適配器模塊。該通信接口支持可配置的數據傳輸速率，包括57.6、115.2和230.4K波特。它還帶有另一個3針鳳凰連接器，用于端接外部24伏直流電源AN-X2-AB-DHRIO還配有內置網絡服務器，允許遠程監控和配置該網關?？赏ㄟ^web服務器啟動的其他支持操作包括診斷數據顯示、配置、上傳配置文件和操作模式設置。這可以通過標準的網絡瀏覽器來完成AN-X2-AB-DHRIO非?；詈霞傻絺鹘y(tǒng)設備的現代控制系統中，以及經濟高效地移植成激和過時的產品。它允許繼續使用這些設備，而不需要完全更換，為客戶提供了一個靈活和實用的現有自動化要求的替代解決方案。AN-X2-AB-DHRIO模塊是艾-布德天 以大網/P至DH+R0網絡連接器，Contr/Lox系列的這通信塊有助于將ControLogx PLC作兼容設備連接到AIlen-Bradlev遠程/0網絡。通信模塊帶有1/0通道，它支持從57.6到230.4千波特的所有遠程/0波特率，該模塊支持隊0到76八進制的架號。該實用程序將遠程/0數據映射到Contrologx計劃數據。該模塊通過使用以太網上的預定連接與Controllogix處理器連接。通信模塊的前面有兩個LED指示燈，用于顯示以太網的連接狀態，另一個LED指示燈用于顯示模塊的內部通信狀態艾倫-布拉德利安-X2-AB-DHRI0 ConroLox通信模塊的工作溫度應設置在0至50得氏度之間?？梢允褂肈N導軌輕松安裝、安X2 AB DHRIO模塊的定功耗為200室安，額定電壓為12伏DC或100毫安，額定電壓為24伏DC，該通信模塊的最大功耗額定值為2.4瓦，安X2 AB DHRIO模塊有助于取代現有的遠程/O PLC。它有助于在不中斷現有控制系統的情況下構建新的控制器程序，并最大限度地減少停機時間。它帶有一個自動配置實用程席，可以發現波特率并映射察散/0以減少配置錯誤、通信模塊配有一R 45 10/100 Mbps以太網端口，一ohenix 3針電源連接器和一Phoenix 3針網絡連接器。

AN-X2-AB-DHRIO

The AN-X2-AB-DHRIO gateway is designed to help customers initiate a phased migration approach to replace or upgrade a traditional remote I/O PLC, HMI, drive, or Flex I/O adapter. These solutions can be implemented by selecting the appropriate mode of operation during initial configuration. The An-X2-AB-DHrio has a built-in web server that can display diagnostic data, configure, upload configuration files, and set operating modes.
The AN-X2-AB-DHRI0 is a communication module manufactured by Allen-Bradley partner company Prosoft Technology, a compact communication device that can be mounted on a desktop or DIN rail. It allows modern programmable automation controllers (PACs) such as Allene-Bradley’s Contrologix and CompactLogix controllers to communicate with devices that employ traditional Remote /0(RI0) and Data HighwayPlus(DH+) communication protocols.
AN-X2-AB-DHRIO has -11 large network /P communication interfaces, supporting 10/10 mps data transfer rates, this end connects the PAC Ray to the gateway, while the available 3-pin Phoenix network connector on the AnX2-A-B-DHRI0 allows the chrysanthemum connection of the device. Such as Allen Bradley’s PLCSLC 500, PanelView, drive and Flex /0 adapter modules. The communication interface supports configurable data transfer rates, including 57.6, 115.2 and 230.4K baud. It also comes with another 3-pin Phoenix connector for terminating AN external 24-volt DC power supply and the AN-X2-AB-DHRIO also comes with a built-in network server that allows remote monitoring and configuration of this gateway. Other supported actions that can be initiated through the web server include diagnostic data display, configuration, uploading configuration files, and operation mode Settings. This can be done via a standard web browser and the AN-X2-AB-DHRIO is very easily integrated into modern control systems for legacy devices, as well as cost-effectively ported to exciting and outdated products. It allows the continued use of these devices without the need for complete replacement, providing customers with a flexible and practical alternative solution to their existing automation requirements. The AN-X2-AB-DHRIO module is AN Ai-Budetien network /P to DH+R0 connector. This communication block in the Contr/Lox series helps to connect ControLogx PLCS as compatible devices to AIlen-Bradlev remote /0 networks. The communication module comes with a 1/0 channel, which supports all remote /0 baud rates from 57.6 to 230.4 kilobord, and the module supports frame numbers from 0 to 76 octal. This utility maps remote /0 data to Contrologx plan data. The module is connected to the Controllogix processor using a scheduled connection over an Ethernet network. The front of the communication module has two LED indicators to show the Ethernet connection status, and another LED indicator to show the internal communication status of the module. The operating temperature of the Allen Bradley An-X2-AB-DHRI0 ConroLox communication module should be set between 0 and 50 degrees Fahrenheit. Easy to install using DN rails, an X2 AB DHRIO module with a fixed power consumption of 200 amps with a rated voltage of 12 V DC or 100 mA with a rated voltage of 24 V DC, this communication module has a maximum power rating of 2.4 watts, an X2 AB DHRIO module helps replace existing remote /O PLCS. It helps build new controller programs without disrupting existing control systems and minimizes downtime. It comes with an auto-configuration utility that detects baud rates and maps scatter /0 to reduce configuration errors, communication modules with an R45 10/100 Mbps Ethernet port, an ohenix 3-pin power connector and a Phoenix 3-pin network connector.
