產品ID:3BSE000435R1
ABB型號名稱:CS513
目錄說明:CS513 IEEE 802.3 LAN-Module
詳細描述:CS513 IEEE 802.3 LAN-Module
技術信息:CS513 IEEE 802.3 LAN-Module
Switch in pos. 1 BIN = MB300(Std)
Switch in pos. 3 BIN = MB300E(Extended)
AC410 and SG400 ask for price.
See replacement for
AC450 3BSE091971R1
CS513AK01
AC460 3BSE091972R1
CS513AK02
海關關稅號:85389091
產品凈重:0.2 kg
產品沒有。: 3 bse000435r1
產品類型:CS513通信接口
當前consump。(a): 5v 0.25, 24v 0.25
合計。功耗(W): 8
重量(長x高x高):23.4cm × 1.8cm × 10.8cm

CS513

在工業現場能夠選擇的通訊接口 CS513 3BSE000435R1 非常多，常見的是如下幾種：串口232、485、以太網、GPIB、USB、無線、光纖等。1、標準串口 CS513 3BSE000435R1 通訊線路簡單，只要一根交叉線即可與PC主機進行點對點雙向通訊。線纜成本低，但傳輸速度慢、不適于長距離通訊。消費類PC機也逐漸取消了該接口，多存在于工控機及部分通信設備中。工控機在安裝完系統及必要的驅動后，其串口便可直接使用，網上也有許多流行的串口調試工具可用于測試儀器。用戶二次開發通訊程序也相對簡單。
在AC 800M控制器系統聯機之前，調查環境條件適用。特別注意以下事項：
?控制器不得暴露在超過給定值的條件下在相關技術規范中。
?控制器不得在接觸強電的環境中使用干擾電機會產生超過水平的干擾允許用于設備，例如在維修工作期間。
ABB CS513 3BSE000435R1 應用DCS/PLC
?處理所有產品時，必須采取適當?shù)念A(yù)防措施靜電損壞。
?控制器不得暴露在陽光直射下。重要軟件檢查
?使用系統的故障監測設施來防止事故或?yàn)?zāi)難。
?如有疑問，請?jiān)趫?zhí)行更改前進行檢查重要硬件注意事項
?在任何情況下，都不要斷開電源功能系統。之前，務必使用正確的系統關閉程序斷開電源

CS513

Product ID:3BSE000435R1
ABB model name :CS513
Directory Description :CS513 IEEE 802.3 LAN-Module
Description :CS513 IEEE 802.3 LAN-Module
Technical information :CS513 IEEE 802.3 LAN-Module
Switch in pos. 1 BIN = MB300(Std)
Switch in pos. 3 BIN = MB300E(Extended)
AC410 and SG400 ask for price.
See replacement for
AC450 3BSE091971R1
CS513AK01
AC460 3BSE091972R1
CS513AK02
Customs Tariff number :85389091
Net weight: 0.2kg
The product does not. : 3 bse000435r1
Product Type :CS513 Communication interface
Current consump. (a): 5v 0.25, 24v 0.25
Total. Power consumption (W): 8
Weight (length x height x height):23.4cm x 1.8cm x 10.8cm
In the industrial site can choose the communication interface CS513 3BSE000435R1 is very many, the common are the following: serial 232, 485, Ethernet, GPIB, USB, wireless, optical fiber and so on. 1, the standard serial port CS513 3BSE000435R1 communication line is simple, as long as a cross line can be point-to-point two-way communication with the PC host. The cable cost is low, but the transmission speed is slow and not suitable for long-distance communication. Consumer PCS have also gradually canceled the interface, which exists in industrial computers and some communication equipment. After the installation of the system and the necessary driver, the serial port of the industrial computer can be used directly, and there are many popular serial debugging tools on the Internet that can be used for testing instruments. It is also relatively easy for users to redevelop communication programs.
Before the AC 800M controller system comes online, investigate the applicable environmental conditions. Particular attention is paid to the following:
? The controller shall not be exposed to conditions exceeding the given values in the relevant technical specifications.
? The controller must not be used in an environment exposed to strong electricity to generate interference above the level allowed for equipment, such as during maintenance work.
ABB CS513 3BSE000435R1 Application DCS/PLC
? Appropriate precautions must be taken for electrostatic damage when handling all products.
? The controller must not be exposed to direct sunlight. Critical software inspection
? Use the system’s fault monitoring facilities to prevent accidents or disasters.
? If in doubt, check important hardware considerations before making changes
? Do not, under any circumstances, disconnect the power function system. Before doing so, be sure to disconnect the power using the correct system shutdown procedure

CS513
