穆格提供各種自由可編程的運動控制器，每個都設計有專門的功能，以滿足一系列客戶的要求。不管你的申請如何，我們有個動議
控制器將滿足您的要求。MSC 1和MSC 1運動控制器
MSC1和MSCll運動控制器高
具有PLC功能的高性能運動控制器是復雜的集中式和分散式應用的理想選擇，這些模塊都是為類似的任務而設計的，只是接口和性能不同。這些運動控制器內置IP20保護，并安裝在電子柜中的DIN導軌上
MSC 運動控制器提供高分辨率模擬輸入/輸出和位置傳感器接口。它設計用于快速和精確的兩抽環控制。MSC 運動控制器最適合需要通過模擬接口控制一個或兩個執行器的應用。
mscll運動控制器具有多個現場總線
接口和四個位置傳感器接口。它被設計用于閉環控制，有或沒有多個電動或液壓軸的輪廓生成。msc和msl運動控制器的綜合功能可以通過額外的高分辨率模擬和數字/0和通信模塊進行擴展，擴展模塊夾在運動控制器的側面，并通過內部擴展總線(E-Bus)進行電子連接

D136-001-007

為了控制復雜的分散應用程序，包括兩個can總線接口。
MSC I 是帶 PLC 功能并配備高分辨率模擬輸入/輸出以及位置傳感器接口的高性能伺服控制器。其專門的設計可實現兩臺液壓伺服作動器快速準確的閉環控制。得益于其模塊式結構及采用通用標準，系統可便捷靈活地安裝配置。運動控制器是可編程多軸（MSD）伺服驅動系統的一部分，使用穆格伺服驅動器的組合。MSD的運動控制器負責協調和同步軸，并傳達通過多種現場總線協議的主機和其他PLC。可以控制機器的進程。它是專為速度和位置提供多達30個軸的閉環控制而設計的。
MOOG伺服控制器MSC
?可自由編程的多軸控制器
?使用IEC 61131開發環境進行編程
MACS（模擬軸控制軟件）
?集成PLC功能
?實現快速精確的控制
（例如位置、速度和力）
?適用于電動和液壓驅動器
?具有循環時間的可自由定義的控制器結構
從400μs
?硬件功能可以通過MACS參數化
軟件
?基于PowerPC的處理器
?內存：4 MB RAM；4 MB閃存EEPROM

D136-001-007

Moog offers a wide range of freely programmable motion controllers, each designed with specialized features to meet a range of customer requirements. Whatever your petition, we have a motion, okay
The controller will meet your requirements. MSC 1 and MSC 1 motion controllers
MSC1 and MSCll motion controllers high
High-performance motion controllers with PLC capabilities are ideal for complex centralized and decentralized applications where the modules are all designed for similar tasks with different interfaces and performance. These motion controllers have built-in IP20 protection and are mounted on DIN rails in the electronic cabinet
The MSC Motion controller provides a high-resolution analog input/output and position sensor interface. It is designed for fast and precise two-pull ring control. The MSC motion controller is best suited for applications where one or two actuators need to be controlled through an analog interface.
The mscll motion controller has multiple fieldbuses
Interface and four position sensor interfaces. It is designed for closed-loop control, with or without the profile generation of multiple electric or hydraulic shafts. The combined functionality of the msc and msl motion controllers can be extended with additional high-resolution analog and digital /0 and communication modules that are clamped to the side of the motion controller and electronically connected via an internal expansion bus (E-Bus)
To control complex decentralized applications, two can bus interfaces are included.
The MSC I is a high performance servo controller with PLC capability and a high resolution analog input/output and position sensor interface. Its special design enables fast and accurate closed-loop control of two hydraulic servo actuators. Thanks to its modular structure and common standards, the system can be easily and flexibly installed and configured. The motion controller is part of a programmable multi-axis (MSD) servo drive system that uses a combination of Moog servo drives. The MSD motion controller is responsible for coordinating and synchronizing axes and communicating the host and other PLCS through multiple fieldbus protocols. You can control the process of the machine. It is designed to provide closed-loop control of up to 30 axes for speed and position.
MOOG Servo controller MSC
? Freely programmable multi-axis controller
? Programming using the IEC 61131 development environment
MACS (Analog Shaft Control Software)
? Integrated PLC function
? Fast and precise control
(e.g. position, velocity, and force)
? Suitable for electric and hydraulic drives
A freely definable controller structure with cycle time
From 400μs
? Hardware functions can be parameterized via MACS
software
? PowerPC-based processor
? Memory: 4 MB RAM; 4 MB flash EEPROM

D136-001-007
