作為Indramat?DKC系列的一部分，DKC02.3-040-7-FW是力士樂博世生產的數字驅動控制器。DKC02.3-040-7-FW?驅動控制器是?ECODRIVE03 驅動套件的一部分。ECODRIVE03?是一種智能自動化系統，具有適用于單軸和多軸控制任務的卓越功能。ECODRIVE?驅動器有多種變體，包括 ECODRIVE01、ECODRIVE03 和?ECODRIVE Cs。每個驅動器系列還具有不同的控制接口，包括并行，SERCOS，Profibus，模擬，CANopen或Interbus。ECODRIVE03固件可以針對某些應用運行同步和異步電機。

DKC02.3-040-7-FW?是?02 系列 3 版控制器。DKC02.3-040-7-FW?的額定電流為 40 A，而直流母線標稱電壓為 DC 700 V。此特定驅動器使用?SERCOS 接口進行命令通信。此驅動器上的固件在出廠時分配，性質未指定。如有必要，可以拆卸和更換固件編程模塊。編程模塊包含參數模塊和固件模塊。參數模塊用于用戶特定的參數，而固件模塊用于特定于單元的固件。與某些DKC同類產品不同，此特定驅動器控制器不具有特定的固件版本。

DKC02.3-040-7-FW

如前所述，DKC02.3-040-7-FW使用SERCOS或串行實時通信系統接口。SERCOS接口有兩個光纖連接，用于連接到更高級別的控制器。該驅動控制器非常適合具有多軸系統的機器，例如打印機。?保修期為一年。

REXROTH DKCO2.3-040-7-FW交流同服放大器驅動控制器
德國博世公司生產的DKCO23-040-7-FW是DKC系列的交流同服放大器驅動控制器。DKC02.3-040-7-FW的額定電流為40A，DC總線標稱電壓為DC700V。這個同服驅動器有一個版本3，并帶有標準固件。

DKC02.3-040-7-FW

As part of the Indramat DKC series, the DKC02.3-040-7-FW is a digital drive controller produced by Rexroth Bosch. The DKC02.3-040-7-FW Drive controller is part of the ECODRIVE03 drive package. The ECODRIVE03 is an intelligent automation system with excellent features for both single-axis and multi-axis control tasks. There are several variants of the ECODRIVE, including ECODRIVE01, ECODRIVE03, and ECODRIVE Cs. Each drive family also has a different control interface, including parallel, SERCOS, Profibus, analog, CANopen or Interbus. The ECODRIVE03 firmware can run synchronous and asynchronous motors for certain applications.

DKC02.3-040-7-FW is the 3rd version of the 02 series controller. The DKC02.3-040-7-FW has A rated current of 40 A and a nominal DC bus voltage of 700 V DC. This particular drive uses the SERCOS interface for command communication. The firmware on this drive is factory assigned and the nature is not specified. If necessary, the firmware programming module can be removed and replaced. Programming module includes parameter module and firmware module. The parameter module is for user-specific parameters, while the firmware module is for cell-specific firmware. Unlike some DKC equivalents, this particular drive controller does not have a specific firmware version.

As mentioned earlier, DKC02.3-040-7-FW uses SERCOS or serial real-time communication system interfaces. The SERCOS interface has two fiber connections for connecting to higher level controllers. The drive controller is ideal for machines with multi-axis systems, such as printers. The warranty period is one year.

REXROTH DKCO2.3-040-7-FW AC co-service amplifier drive controller
DKCO23-040-7-FW produced by Bosch GMBH is a DKC series AC co-service amplifier drive controller. The DKC02.3-040-7-FW has a rated current of 40A and a nominal DC bus voltage of DC700V. This codriver is available in version 3 and comes with standard firmware.

DKC02.3-040-7-FW
