GEDS200DCFBG1BGB 電流反饋卡 DS200SDCCG1AFD
有關反饋的定義與概念，什么是反饋，將輸出量(電壓或電流)的一部分或全部通過一定的電路形式作用到輸入回路，用來影影響其輸入量(放大電路的輸入電壓或輸入電流)的措施稱為反饋。一、什么是反饋在電子電路中，將輸出量(電壓或電流)的一部分或全部通過一定的電路形式作用到輸入回路，用來影影響其輸入量 (放大電路的輸入電壓或輸入電流)的措施稱為反饋。二、反饋的定義“反饋的定義定義1:系統過去的行為結果返回給系統，以控制未來的行為。定義2:部分信號從雙端口網絡輸出端向輸入端的回傳，或從傳輸通道上的一點向途中已通過的一點的回傳

DS200DCFBG1BGB

DS200DCFBG1B是通用電氣公司為Mark V板系列生產的電源板，AC2000、CB2000、DC2000、FC2000ME2000和EX2000系列機器可以將板安裝在驅動器中。安裝后，此卡可以提供控制級電源和機箱風扇電源去車道，額定電壓在38到115伏之間可以通過控制電源變壓器直接提供給電路板。電路板的頻率取決于輸入電壓，但范圍可以從0至500千赫
該板具有許多電路，用于為板和安裝的驅動器供電，DS200DCFBG1B包括電機磁場電源、驅動器、交流/DC監控和控制級電源電路。這十二個跳線和七DIP開關為用戶提供可配置的系統洗項，保險絲開關診斷使用兩LED和一個雷虹燈指示燈在黑板上找到的。二個保護保險絲防止電源中斷，可以使用監控電壓五個測試點集成在電路板上
應遵循制造商提供的DS200DCFBG1B和已安裝驅動器的安裝和存儲參數，這將防止對兩個單元的任何意外或可預防的損壞。有關電路板布線和安裝的完整指南，請參考設備手冊和數據表。最初，該板和Mark V系列的技術支持由制造商通用電氣公司提供。

DS200DCFBG1BGB

GEDS200DCFBG1BGB Current Feedback card DS200SDCCG1AFD
The definition and concept of feedback, what is feedback, part or all of the output (voltage or current) through a certain circuit form to the input loop, used to influence its input (input voltage or input current of the amplifier circuit) measures called feedback. In an electronic circuit, a part or all of the output (voltage or current) is applied to the input loop through a certain circuit form, and the measure used to influence its input (the input voltage or input current of the amplifier circuit) is called feedback. Definition of feedback Definition 1: The results of past behavior of the system are returned to the system to control future behavior. Definition 2: Part of the signal is transmitted back from the output to the input of a two-port network, or from a point on the transmission channel to a point that has passed along the way
The DS200DCFBG1B is a power board produced by General Electric for the Mark V board series, which can be mounted in a drive for AC2000, CB2000, DC2000, FC2000ME2000 and EX2000 series machines. When installed, the card can provide control level power and chassis fan power to the lane, and the rated voltage between 38 and 115 volts can be supplied directly to the board via the control power transformer. The frequency of the board depends on the input voltage, but can range from 0 to 500 KHZ
The board has a number of circuits for powering the board and mounted drivers, and the DS200DCFBG1B includes a motor field power supply, a driver, AC /DC monitoring and control-level power circuits. The twelve jumpers and seven DIP switches provide users with configurable system wash items, and the fuse switch diagnostics are found using two leds and a thunderbow indicator light on the board. Two protective fuses prevent power outages and can be used to monitor voltage with five test points integrated on the circuit board
The installation and storage parameters of DS200DCFBG1B and installed drives provided by the manufacturer should be followed, which will prevent any accidental or preventable damage to both units. For complete guidelines on circuit board wiring and installation, refer to the device manual and data sheet. Initially, technical support for the board and the Mark V series was provided by manufacturer General Electric.

DS200DCFBG1BGB
