產品說明
通用電氣DS200DCFBG1BKC是Mark V系列電源板。當安裝在驅動器中時，該板為機柜風扇以及系統的控制級電源供電。在GE的驅動系統中，該板與兼容DC2000、AC2000、FC2000、CB2000和ME2000系列驅動器。電路板的標稱額定源輸入可以安全地測量38伏和115伏交流電壓。該卡產生的輸出頻率可以在任何地方測量0和500千赫取決于輸入的電壓。

五個獨立電路可在DS200DCFBG1BKC上找到。這些包括控制電平電源電路、驅動器電路、電機磁場電源電路以及交流和DC監控電路。變頻器上保險絲的診斷信息通過呈現給用戶兩個LED指示燈和一個霓虹燈指示器。三個保護保險絲集成在電路板上，保護電流不受干擾。當使用其中一個時，檢查電路板上的電壓電平很簡單五個測試點在卡片上找到的。為用戶提供了許多可配置的設置，以適應特定的工作需求。十二個跳線和七個DIP開關可根據用戶要求進行配置。

DS200DCFBG1BKC

電源輸入：該電源板通常接受來自外部電源或電網的電源輸入。具體的輸入要求可以在產品規格和用戶手冊中找到。

輸出通道：DS200DCFBG1BKC電源板提供多個輸出通道，用于連接和供電其他設備，如控制器、接口模塊、傳感器等。

電源保護功能：該電源板通常具有多種保護功能，包括過載保護、短路保護、過壓保護等。這些保護功能有助于保護電源板和連接的設備免受電力問題可能帶來的損壞。

可靠性和穩定性：GE DS200DCFBG1BKC電源板設計用于工業環境，具有高可靠性和穩定性，能夠在惡劣的工作條件下長時間運行。

兼容性：該電源板通常與GE的控制系統和其他設備兼容，可以與其他模塊和組件配合使用。

DS200DCFBG1BKC

Product description
The GE DS200DCFBG1BKC is a Mark V series power supply board. When mounted in a drive, the board powers the cabinet fan as well as the system’s control level power supply. In GE’s drive system, the board is compatible with DC2000, AC2000, FC2000, CB2000 and ME2000 series drives. The board’s nominal rated source input can safely measure 38 volts and 115 volts AC. The output frequency produced by the card can be measured anywhere from 0 to 500 KHZ depending on the input voltage.

Five individual circuits can be found on DS200DCFBG1BKC. These include control level power supply circuits, driver circuits, motor field power supply circuits, and AC and DC monitoring circuits. The diagnostic information of the fuses on the inverter is presented to the user by two LED indicators and a neon indicator. Three protective fuses are integrated into the circuit board to protect the current from interference. When using one of the five test points found on the card, it is simple to check the voltage level on the board. Users are provided with a number of configurable Settings to suit specific work needs. Twelve jumpers and seven DIP switches can be configured according to user requirements.

Power input: The power board usually accepts power input from an external power source or the grid. Specific input requirements can be found in the product specifications and user manuals.

Output channels: The DS200DCFBG1BKC power supply board provides multiple output channels for connecting and powering other devices, such as controllers, interface modules, sensors, etc.

Power protection function: The power supply board usually has a variety of protection functions, including overload protection, short circuit protection, overvoltage protection, etc. These protection features help protect the power board and connected devices from possible damage caused by power problems.

Reliability and stability: The GE DS200DCFBG1BKC power supply board is designed for use in industrial environments with high reliability and stability, capable of operating for long periods under harsh operating conditions.

Compatibility: The power board is generally compatible with GE’s control systems and other devices, and can be used with other modules and components.

DS200DCFBG1BKC
