通用電氣公司制造了DS200LDCCH1ALA板作為驅動控制和局域網(LAN)通信卡。這張卡是作為Mark V系列驅動板。開車穿過直接自動2000系列將此卡安裝在其驅動器機柜中。該板提供一系列功能，如器件、電機和I/O控制功能。

這種驅動控制和局域網通信板的特點四個微處理器過濾卡信號。發送到主板的數字和模擬I/O由板載驅動控制處理器(DCP)接收和過濾。通過局域網控制處理器(LCP)過濾輸入到變頻器的局域網系統在船上找到的。剩下的兩個處理器電機控制處理器(MCP)和協同電機處理器(CMP)，互相配合工作。這MCP為數字I/O通信提供了初始處理空間。如果信號所需的計算超過了MCP提供的空間功率，CMP將補充處理能力。該板由一個可連接的字母數字鍵盤。
GE 的 EX2100e 勵磁控制系統是一種支持軟件的發電機控制系統，適用于蒸汽（包括核能）、燃?xì)夂退Πl(fā)電機。EX2100e 具有用于新安裝和現有系統改造的配置。EX2100e 控制硬件和軟件是 Mark* VIe 控制產品線的組成部分。

勵磁系統、渦輪機控制、靜態啟動器、分布式控制系統 (DCS) 和不需要第三方接口或網關的人機界面 (HMI) 之間的集成是無縫的。

對于獨立改造應用，可通過多種協議（包括 Modbus/TCP 或硬接線）實現與工廠控制系統的緊密集成。

DS200LDCCH1ALA

在有意義的上下文中呈現數據
ControlST 整合整個工廠的重要數據，包括來自外部系統的數據，否則這些數據將不可用，并將其呈現在有意義的環境中，從而降低系統成本。

在正確的時間獲得正確的信息，工程師可以更有效地分析過程趨勢并調整控制軟件，操作員可以更快地響應警報和操作中斷，維護團隊可以查明問題區域，主動做出反應并保持流程在線。

ControlST 軟件套件包括幾個高性能工具：

WorkstationST* HMI 和 Historian 通信軟件
ToolboxST* 過程配置和診斷軟件，用于過程、SIL、勵磁和功率轉換
TrenderST* 提供結合 SOE 和警報點的集成實時和歷史數據
AlarmViewer 提供符合 ISA 18.2 的警報管理
用于高效全廠通信、監控和資產管理的其他軟件包

旋轉勵磁機調節器
Ex2100e 產品系列包括單工和冗余自動電壓調節器系統，通常用于較小的勵磁電流。該解決方案專門設計用于解決所有尺寸的發電機，并嵌入所有必要的控制、限制和保護，以幫助發電機安全運行。這種靈活的勵磁產品可以定制以改造大多數配置。

靜態勵磁系統
對于更高的勵磁電流，基于晶閘管的 EX2100e 靜態勵磁系統有多種配置可供選擇，以提供靈活性并經濟地滿足勵磁電流要求。其控制架構采用單工配置或冗余（三重模塊化冗余）配置與轉換器冗余（熱備份、n-1、n-2）相結合，以實現最高可用性。

改造發電機控制
為實現最佳改造，GE 提供數字前端 (DFE) 作為勵磁系統的控制部分，用于使用最新的控制技術升級現有勵磁系統，同時保留現有的電源轉換部分，最大限度地降低成本和停機時間。

發電機控制面板
勵磁系統還可以與同步器和發電機保護相結合，以提供完整的發電機控制。

DS200LDCCH1ALA

Ge manufactured the DS200LDCCH1ALA board as a driver control and local area network (LAN) communication card. This card is used as a Mark V Series driver board. Drive through the Direct Automatic 2000 series to install this card in its drive cabinet. The board offers a range of features such as device, motor and I/O control functions.

This drive control and LAN communication board features four microprocessors that filter card signals. The digital and analog I/O sent to the motherboard is received and filtered by the onboard Drive Control Processor (DCP). Input to the inverter is filtered through the LAN control Processor (LCP) found on board the LAN system. The two remaining processors, the Motor Control processor (MCP) and the Co-motor processor (CMP), work in tandem with each other. This MCP provides initial processing space for digital I/O communications. If the computation required for the signal exceeds the spatial power provided by the MCP, the CMP will supplement the processing power. The board consists of a connectable alphanumeric keyboard.
GE’s EX2100e excitation control system is a software-enabled generator control system for steam (including nuclear), gas and hydro generators. The EX2100e has a configuration for new installations and retrofits of existing systems. The EX2100e control hardware and software are an integral part of the Mark* VIe control product line.

The integration between excitation systems, turbine controls, static starters, distributed control systems (DCS) and human machine interfaces (Hmis) that do not require third-party interfaces or gateways is seamless.

For stand-alone retrofit applications, tight integration with plant control systems is possible through a variety of protocols, including Modbus/TCP or hardwired.

Present data in a meaningful context
ControlST integrates important data throughout the plant, including data from external systems that would otherwise be unavailable, and presents it in a meaningful context that reduces system costs.

With the right information at the right time, engineers can more effectively analyze process trends and adjust control software, operators can respond more quickly to alarms and operational disruptions, and maintenance teams can pinpoint problem areas, respond proactively and keep processes online.

The ControlST software suite includes several high-performance tools:

WorkstationST* HMI and Historian communication software
ToolboxST* Process configuration and diagnostic software for process, SIL, excitation and power conversion
TrenderST* provides integrated real-time and historical data combined with SOE and alert points
AlarmViewer provides ISA 18.2-compliant alarm management
Additional software packages for efficient plant-wide communication, monitoring, and asset management

Rotary exciter regulator
The Ex2100e product family includes simplex and redundant automatic voltage regulator systems, typically used for small excitation currents. The solution is specifically designed to address generators of all sizes and is embedded with all the necessary controls, limitations and protections to help generators operate safely. This flexible excitation product can be customized to retrofit most configurations.

Static excitation system
For higher excitation currents, the thyristor-based EX2100e static excitation system is available in a variety of configurations to provide flexibility and economically meet excitation current requirements. Its control architecture uses a simplex configuration or redundancy (triple modular redundancy) configuration combined with converter redundancy (hot backup, n-1, n-2) for maximum availability.

Retrofit generator control
For optimal retrofit, GE offers a digital front end (DFE) as the control portion of the excitation system to upgrade the existing excitation system with the latest control technology, while preserving the existing power conversion portion to minimize cost and downtime.

Generator control panel
Excitation systems can also be combined with synchronizers and generator protection to provide complete generator control.
