產品編號：3BSE003127R1

ABB 型號名稱：DSAI130D

目錄說明：DSAI130D 模擬輸入板 16 CH.12

詳細描述：DSAI130D 模擬輸入板

16 路輸入，帶 4 組濾波時間，12 位，差分輸入

+/-10V，+/-10MA，0.03%

CONV.TIME 20 MS

CUT OFF FREQ。10HZ,30HZ

100HZ,300HZ

關稅稅號：85389091

產品凈重：0.475公斤

模擬量輸入模塊DSAI130D 3BSE003127R1 是一種將模擬量遠距離采集到計算機上的裝置。該系統采用RS-485總線作為數據通信線路，提供模擬量轉換485功能，可同時將模擬量輸入模塊，并通過RS-485總線傳送給計算機。
以RS-485接口為通信接口，可將多個模塊合并，實現多路模擬信號的傳輸，并可分散配置于485線路上，通過地址碼識別，可直接與MODBUSRTU協議的組態軟件連接。

模擬量輸入模塊DSAI130D 3BSE003127R1 主要負責采集模擬信號。壓力傳感器采集到的模擬信號被采集到，然后將其采集到的模擬信號進行處理。傳感器數據包括模擬電壓、電流、熱阻、熱電偶、溫度等，再通過總線傳輸?shù)接?jì)算機的智能模塊。

DSAI130D

推出了CMS-700，允許通過內置的網絡服務器進行數據收集、分析和下載，以管理電源并優化電路監控系統的能效分析。該系統擴展了一代開放式核心傳感器，無需斷開電源即可連接到現有裝置，提供一定程度的測量精度。

產品特點是開芯式傳感器，可連接到現有裝置。
CMS-700能源監控單元的加入擴展了ABB電路監控系統解決方案的產品組合，用于建筑物和關鍵電力應用中的分支監控的多通道測量。
CMS-700單元具有開放式核心傳感器，可連接到現有裝置，以實現改造和擴展的靈活性。
所有組件通過一根扁平電纜連接，安裝不需要特殊工具
CMS-700能源監測和控制單元可集成多達96個傳感器，可使用內置網絡服務器、傳輸控制協議/互聯網協議(TCP/IP)或Modbus遠程終端單元(RTU)顯示和處理這些傳感器。CMS-700技術還可以監控高達160安培的交流、DC或混合電流。CMS-700能量監測和控制單元的尺寸使其占用最小的空間，并且不需要外殼中的額外空間。

DSAI130D

Product Number: 3BSE003127R1

ABB model name: DSAI130D

Directory Description: DSAI130D analog input board 16 CH.12

Detailed description: DSAI130D analog input board

16 input, with 4 groups of filtering time, 12 bit, differential input

+/-10V, +/-10MA, 0.03%

CONV.TIME 20 MS

CUT OFF FREQ. 10HZ,30HZ

100HZ,300HZ

Customs number: 85389091

Net weight: 0.475 kg

The analog input module DSAI130D 3BSE003127R1 is a device for remote acquisition of analog data to a computer. The system uses RS-485 bus as the data communication line, provides the analog conversion 485 function, can simultaneously input the analog module, and transmitted to the computer through the RS-485 bus.
With RS-485 interface as the communication interface, multiple modules can be combined to achieve the transmission of multiple analog signals, and can be dispersed on the 485 line, through the address code identification, can be directly connected with the MODBUSRTU protocol configuration software.

Analog input module DSAI130D 3BSE003127R1 is mainly responsible for collecting analog signals. The analog signal collected by the pressure sensor is collected, and then the analog signal collected by the pressure sensor is processed. The sensor data includes analog voltage, current, thermal resistance, thermocouple, temperature, etc., and then transmitted to the intelligent module of the computer through the bus.
Launched the CMS-700, which allows data collection, analysis and download via a built-in web server to manage power and optimize energy efficiency analysis for circuit monitoring systems. The system extends a generation of open core sensors that can be connected to existing units without disconnecting the power supply, providing a degree of measurement accuracy.

The product features an open-core sensor that can be connected to existing devices.
The addition of the CMS-700 Energy Monitoring unit expands ABB’s portfolio of circuit monitoring system solutions for multi-channel measurement of branch monitoring in buildings and critical power applications.
The CMS-700 unit features an open core sensor that can be connected to existing units for flexibility to retrofit and expand.
All components are connected via a flat cable and no special tools are required for installation
The CMS-700 Energy Monitoring and Control unit integrates up to 96 sensors that can be displayed and processed using a built-in network server, Transmission Control Protocol/Internet Protocol (TCP/IP) or Modbus Remote Terminal Unit (RTU). The CMS-700 technology can also monitor AC, DC, or hybrid currents up to 160 amps. The size of the CMS-700 Energy monitoring and control unit allows it to take up minimal space and does not require additional space in the housing.

DSAI130D
