EPQ96-2 DEIF技術規格
電子調速器的控制
積分時間的設置(如變速齒輪箱)
輸出信號的調整
。偏移調整
手動/自動模式
模擬和數字輸出
將J1939 CAN輸入轉換為模擬或PWM輸出
Q96面板安裝
EPQ96-2是一個數字控制的電子裝置，代替普通的電機電位計來控制電子調速器EPO96-2是一個數字控制的電子裝置，代替普通的電機電位計來控制電子調速器、該裝置具有手動和自動模式洗項，并將P/控制器的然電器輸出轉換為控制電壓/電流或PWM信號，作為電子調速器的輸入，EPQ96-2也有一個J1939模擬轉換器。在電源電壓下降的情況下，電位計會自動重置為調整后的預設值，或者在重新連接到電源電壓后，重置為與下降前讀數相同的值。

EPQ96-2

DEIF風速風向儀

DEIF繼電器、DEIF電流表、DEIF電壓表、DEIF雙頻率電壓表、DEIF電能表、DEIF監視器、DEIF指示器

電表 WQR96(MK11)
“繼電器
” RMC-131D/2 AC 220V
轉速表 2951190020 13 – XL192
充電器 DCP-2 2420 output 24V DC, 20A – impr. v. 1x230V AC
傳感器 WSS
電流表 EQ96-X /5A scale range:0-300Ax2
同步檢測繼電器 CSQ-3 Land 415/250/24
變送器 TAS-331DG 型號升級：TAS-331DG，Auxilliary voltage: 440V AC
控制器 GPC-3-D1-E1-F1-J1

EPQ96-2

EPQ96-2 DEIF Technical specifications
Electronic governor control
Integration time Settings (e.g., gearboxes)
Adjustment of output signal
. Offset adjustment
Manual/automatic mode
Analog and digital output
Convert the J1939 CAN input to analog or PWM output
Q96 Panel installation
EPQ96-2 is a digital controlled electronic device, replacing the ordinary motor potentiometer to control the electronic governor EPO96-2 is a digital controlled electronic device, replacing the ordinary motor potentiometer to control the electronic governor, the device has manual and automatic mode cleaning items, The EPQ96-2 also has a J1939 analog converter, which converts the P/ controller’s electrical output into a control voltage/current or PWM signal as input to the electronic governor. In the event of a drop in the supply voltage, the potentiometer automatically resets to the adjusted preset value or, after reconnecting to the supply voltage, to the same value as it read before the drop.
DEIF anemometer

DEIF relay, DEIF ammeter, DEIF voltmeter, DEIF double frequency voltmeter, DEIF energy meter, DEIF monitor, DEIF indicator

Electric meter WQR96(MK11)
relay
” RMC-131D/2 AC 220V
Tachometer 2951190020 13-XL192
Charger DCP-2 2420 output 24V DC, 20A-Imp.V. 1x230V AC
Sensor WSS
Ammeter EQ96-X /5A scale range:0-300Ax2
Synchronous detection relay CSQ-3 Land 415/250/24
Transmitter TAS-331DG Model upgrade: TAS-331DG, Auxilliary voltage: 440V AC
Controller GPC-3-D1-E1-F1-J1

EPQ96-2
