ECT-VGA和ETT-VGA滿足了對功能強大但具有成本效益的操作員接口系統的需求。顯示器是基于像素的16色LCD，具有VGA分辨率，采用TFT有源矩陣或無源彩色STN。

這些像素可尋址顯示器允許我們的Designer for Windows軟件包提供圖形功能。每行最多可包含80個字符。每頁最多可包含30行。提供亮度控制以調整顯示器，以便在幾乎任何條件下都能輕松觀看。顯示變量PLC內部變量可以顯示在許多顯示頁面中的任何一個頁面上。一次可以查看的變量數量僅受顯示大小的限制。
UniOP還提供顯示數據的縮放（線性轉換）。最終值可以用幾種有用的格式顯示，包括條形圖、日期、時間、十進制、位、十六進制、浮點和字符串。

每種數據類型都可以輸入有效范圍驗證的數據。數據輸入ECT-VGA和ETT-VGA為用戶提供八個可配置的功能鍵和八個用戶可定義的LED。模擬觸摸屏增加了創建小到單個字符或大到整個屏幕的觸摸單元的能力。

UniOP還配備了內置電池支持的實時時鐘。來自時鐘的時間和日期信息在PLC中定期更新，以實現基于一天中的時間、星期幾或任何其他周期的處理。安全八級密碼保護方案可保護關鍵系統功能免受意外訪問。

報警UniOP可以監控和顯示多達1024個報警?？梢远x每個警報的屬性和唯一消息。也可能需要操作員確認。UniOP檢測到的最后256個報警事件保留在內部事件列表中。此列表可以在屏幕上查看，也可以在串行打印機上打印以獲得永久記錄。

ETT-VGA

ETT-VGA模塊
*密度范圍從4點到32點，每個模塊。
*模塊率IP20，I類，2/Z0IE 20
某些模塊具有現場側診斷，電子熔斷，或單獨隔離的輸入/輸出。一個遠程端子塊(TB)或線系統需要為每個/模塊。
ControlLogix電源 ?使用ControlLogix電源1756機箱直接到機箱背板提供1.2V，3.3V，5V和24V直流電源。
?每個機箱中選擇一個電源，如果你使用的是標準的電源。
洗擇電源捆綁在一起，如果你打算-個余電源系統的ControlLogix 機箱 MCntrolLogix標準的ControlLogix-XT底盤選擇。標準機箱有4，7，10，13，或17個插槽的ControlLogix-XT底盤是5或7個插槽。插槽填充所需要的空插槽?？蛇x的系統組件包括:操作界面和電腦我們的人機界面和計算機產品，以及與L0B1x控制和通信VetLi架構，使羅克韋爾自動化集成架構策略。
*選擇的PanelView Flus的PelView Plus E電子操作員接口和羅克韋爾自動化的工業化個人電腦硬件?？陕遘浖O(jiān)控軟件FactoryTalk Vew軟件。軟件您選擇的模塊和網絡配置確定的軟件包你需要你的系統進行配和編程*編程ControlLogix系統RSLogix 5000 Enterprise系列軟件。

ETT-VGA

ECT-VGA and ETT-VGA address the need for a powerful yet cost-effective operator interface system. The display is a pixel-based 16-color LCD with VGA resolution using either a TFT active matrix or a passive color STN.

These pixel addressable displays allow our Designer for Windows packages to provide graphics capabilities. Each line can contain up to 80 characters. Each page can contain up to 30 lines. Brightness control is provided to adjust the display for easy viewing in almost any conditions. Display variables PLC internal variables can be displayed on any one of many display pages. The number of variables that can be viewed at a time is limited only by the size of the display.
UniOP also provides scaling (linear conversion) of the display data. The final value can be displayed in several useful formats, including bar chart, date, time, decimal, bit, hexadecimal, floating point, and string.

Each data type can be entered with valid range validation. Data entry ECT-VGA and ETT-VGA provide users with eight configurable function keys and eight user-definable leds. Analog touch screens increase the ability to create touch units as small as a single character or as large as an entire screen.

The UniOP also comes with a real-time clock with built-in battery support. The time and date information from the clock is regularly updated in the PLC to enable processing based on the time of day, day of the week, or any other cycle. Secure eight-level password protection protects critical system functions from accidental access.

Alarm UniOP can monitor and display up to 1024 alarms. Attributes and unique messages can be defined for each alert. Operator confirmation may also be required. The last 256 alarm events detected by UniOP remain in the internal event list. This list can be viewed on the screen or printed on a serial printer for a permanent record.
ETT-VGA module
* Density ranges from 4 to 32 points per module.
* Module rate IP20, Class I, 2/Z0IE 20
Some modules have field side diagnostics, electronic fuses, or individually isolated inputs/outputs. A remote terminal block (TB) or wire system is required for each/module.
ControlLogix power supply? Use the ControlLogix power supply 1756 chassis to provide 1.2V, 3.3V, 5V and 24V DC power directly to the chassis backplane.
? Select a power supply in each case, if you are using a standard power supply.
Wash the optional power supply bundled together if you plan to – a residual power system for the ControlLogix chassis MCntrolLogix standard ControlloGIX-XT chassis option. The standard chassis has 4,7,10,13, or 17 slots – the ControlLogix-XT chassis is 5 or 7 slots. Slot fills the required empty slot. Optional system components include: Operating interfaces and computers our HMI and computer products, as well as an integrated architecture strategy with the L0B1x control and communication VetLi architecture that enables Rockwell Automation.
* Selected PanelView Flus PelView Plus E electronic operator interface and Rockwell Automation industrial PC hardware. Kolo Software Monitoring software FactoryTalk Vew software. Software You select the module and network configuration to determine the package you need for your system to be configured and programmed * Program ControlLogix System RSLogix 5000 Enterprise series software.

ETT-VGA
