?？怂共┝_(施耐德電氣)
產品編號:FBM242
產品類型:外部來源，離散輸出接口模塊
特性:16路離款輸出，支持15至60 V dc、120 V ac/125 V dc、240 V ac電壓下的離輸出信號，每輸入和輸出均為電流隔離，與外部激勵一起使用時為組隔離，緊湊、堅固的設計適合G3類(惡劣)環境中的外殼，執行離散/0或梯形邏輯程序，具有以下可配置選項輸入濾波時間、故障安全配
置、故障、安全回退以及持續或瞬時輸出
輸入電壓范圍(幾余):24伏直流電+5%，-10%
功耗(最大):24伏直流電,時為3瓦(最大值)

FBM242

FBM242

散熱:24伏直流電時為6.5瓦(最大值)(所有輸出均為1.5安
校準要求:模塊和終端組件不需要校準。
溫度模塊:-20至+70攝氏度(-4至+158華氏度)
終端組件PVC:-20至+50攝氏度(-4至+122華氏度
相對濕度:5至95%(非冷凝)
尺寸(長x寬x高):10.4厘米x 4.5厘米x 11.4厘米
重量:0.284千克
運輸重量:2公斤

FBM242

Foxboro (Schneider Electric)
Product number :FBM242
Product Type: External source, discrete output interface module
Features :16 off-output supports off-output signals at 15 to 60 V dc, 120 V ac/125 V dc, 240 V ac voltages, each input and output is current isolated, group isolated when used with external excitation, compact, rugged design for enclosures in G3 (harsh) environments. Execute discrete /0 or ladder logic programs with the following configurable options for input filtering time, fail-safe configuration
Reset, failure, safety rollback, and continuous or instantaneous output
Input voltage range: 24V DC +5%, -10%
Power consumption (Max.):24 volts DC, 3 watts (Max.)
Heat dissipation: 6.5 watts at 24 volts DC (Max.)(all outputs are 1.5 amps
Calibration requirements: Modules and terminal components do not require calibration.
Temperature module :-20 to +70 degrees Celsius (-4 to +158 degrees Fahrenheit)
End component PVC:-20 to +50 degrees Celsius (-4 to +122 degrees Fahrenheit)
Relative humidity :5 to 95%(non-condensing)
Dimensions (L x W x H):10.4 cm x 4.5 cm x 11.4 cm
Weight :0.284 kg
Shipping weight :2 kg

FBM242
