現場總線段之間也有電流隔離，從而防止多段接地故導致多段故障，每個段都有自己的現場總線功率調節器和電流限制。當安裝單個或幾余F80x模塊時，現場總線段的終端自動保持。AnF809F-Plus診斷模塊可選擇安裝在載體上，自動收和分發八個現場總線段的診斷信息。通過將F809FPIus作為現場總線設備分配給1段或8段供電段，或通過單獨的現場總線段，可在Foxborocontrol系統中查看測量參數，基板上提供了獨立段的連接，

FBMSVH

有關更多信息，請參見F809F-Plus產品規格。幾余24V DC(標稱)輸入電源可以使用Foxboro l/a標準放大器連接器車接到F810底板。F80x電源模塊和F809F-Pus現場總線診斷模塊可以由同一個電源供電，或者，對于標準Foxboro電源不能提供足夠電流容量的裝置，可以連接外部24V DC電源?，F(xiàn)場接線連接可采用可插拔螺釘端子(F810-PS)或可插拔彈夾端子(F810-PC)。

FBMSVH

There is also current isolation between the fieldbus segments to prevent multiple ground faults, each with its own fieldbus power regulator and current limit. When one or more F80x modules are installed, the terminal of the fieldbus segment is automatically held. The AnF809F-Plus diagnostic module can be optionally mounted on a carrier to automatically receive and distribute diagnostic information across eight fieldbus segments. The measurement parameters can be viewed in the Foxborocontrol system by assigning the F809FPIus as a fieldbus device to a 1 – or 8-segment power supply segment, or through a separate fieldbus segment. Connections for individual segments are provided on the substrate, see F809F-Plus product specifications for more information. a few more 24V DC(nominal) input power supplies can be connected to the F810 chassis using the Foxboro l/a standard amplifier connector. The F80x power supply and F809F-Pus fieldbus diagnostic module can be powered from the same power supply, or, for devices where the standard Foxboro power supply does not provide sufficient current capacity, an external 24V DC power supply can be connected. Field wiring can be connected using a pluggable screw terminal (F810-PS) or a pluggable clip terminal (F810-PC).
