I/A系列?系統現場控制處理器270 (FCP270)模塊安裝在底板上并分布
控制系統(DCS)現場總線模塊取代APACS+控制和I/O模塊，并連接現有的
現場設備通過2mbps的HDLC現場總線和高速以太網網絡連接到I/A系列系統
特性
?從專有DCS遷移到
最先進的開放式I/A系列系統
?高級I/A系列控制，單點
配置
?更直接的控制性能比任何
網關設備可以提供
?與整個系統替換相比節省的成本
保留現有的流程接口和
布線和最小化工藝停機時間
?單一供應商服務和供應。
FCP270
FCP270
概述
I/A系列系統DCS現場總線模塊
用于APACS+?自動化系統的遷移
由西門子?能源與自動化制造，
fbm直接插入
成現有的電子窩來替代工藝
輸入輸出模塊。
I/A系列系統DCS FBM家族提供了一個
從APACS+進程I/O遷移路徑
組件到I/A系列顯示和監控
功能。沒有額外的通信設備
必需的。沒有多廠商通信軟件
需要許可。
I/A系列系統DCS FBM家族取代
APACS+ I/O模塊。一旦整合，過程
完全由先進的I/A系列控制
算法集。
I/A系列系統DCS FBM產品包括
連接器，使集成的原始過程
信號到I/A系列系統，同時保持現場
接口和布線。它提供對所有進程的訪問
信號連接到APACS+系統
提供Field之間的連接
終端組件和I/A系列
系統。所有過程信號完全集成
進入I/A系列系統通過使用的過程
數據顯示，歷史，報警和
控制。
操作員功能和工程配置如下
由I/A系列系統完成
I/A系列操作員工作站。因為所有的過程
值成為I/A系列系統的一部分
配置數據由系統維護
本機I/A系列配置。
此遷移路徑提供了所有的工廠操作
I/A系列系統的強大和靈活性。
FCP270
I/A Series? system Field Control Processor 270 (FCP270) modules mounted on a baseplate and distributed
control system (DCS) Fieldbus Modules replace the APACS+ Control and I/O modules and connect existing
field devices to the I/A Series system via a 2 Mbps HDLC Fieldbus and high-speed Ethernet network
FEATURES
? Migration from proprietary DCS to a
state-of-the-art open I/A Series system
? Advanced I/A Series control with a single point of
configuration
? More direct control performance than any
gateway device could offer
? Cost savings over total system replacement by
preserving the existing process interface and
wiring and minimizing process downtime
? Single vendor service and supply.
OVERVIEW
The I/A Series system DCS Fieldbus Modules (FBMs)
are for migration of APACS+? automation systems
manufactured by Siemens? Energy & Automation,
Inc. and Moore Products Co. The FBMs plug directly
into an existing electronic nest to replace process
input and output modules.
The I/A Series system DCS FBM family provides a
migration path from APACS+ process I/O
components to I/A Series display and supervisory
functions. No additional communication devices are
required. No multi-vendor communication software
licensing is required.
The I/A Series system DCS FBM family replaces the
APACS+ I/O modules. Once integrated, the process
is controlled entirely by the advanced I/A Series
algorithm set.
The I/A Series system DCS FBM product includes
connectors to enable integration of original process
signals to I/A Series systems while keeping the field
interface and wiring. It provides access to all process
signals connected to the APACS+ system by
providing the connection between the Field
Termination Assemblies (FTAs) and the I/A Series
system. All process signals become fully integrated
into the I/A Series system through the use of process
data for operator display, history, alarming and
control.
Operator functions and engineering configuration are
accomplished by the I/A Series system at any
I/A Series operator workstation. Because all process
values become part of the I/A Series system, all
configuration data is maintained by the system as
native I/A Series configurations.
This migration path provides plant operations with all
the power and flexibility of the I/A Series system.
