GDD471A001 ABB 控制卡模塊
首先，要明確一點，無論是PLC，還是運動控制器、運動控制卡，它們的本質都是一種控制器，主要負責自動化系統中運動軸的控制，同時也支持輸入輸出信號的控制。從區別來看，主要有以下幾點:
1、GDD471A001 ABB 控制卡模塊PLC的專長在于邏輯10控制，實現一些復雜的邏輯控制都很易。對于運動控制，一般低端的PLC主要是通過高速輸出點來進行脈沖控制，中高端PLC一般會通過總線的方式來進行控制，常用的總線包括Profinet、EtherCAT、CC-Link等.
2、GDD471A001 ABB 控制卡模塊運動控卡通過PCI插槽將控制卡插在PC的主機上，也可以通過以大網連接到PC主機上;利用高級編程語言C++、C#、VB、http:/VBNETlabview等編程語言進行開發;編程中使用運動控制卡廠商提供的控制卡AP接口函數，來實現對控制卡資源的使用;運動控制卡也分為脈沖型和總線型，一般總線型要比脈沖型稍貴一些。

GDD471A001

3、GDD471A001 ABB 控制卡模塊PLC具有工作可靠，編程簡單等優點，但其運動控制功能相對簡單，PLC的應用過程中主要通過PLC+HMI，這就導致可視化界面受到了一定的限制，因此現在基于PLC的上位機應用也越來越廣泛;
運動控制卡可以利用PC強大的功能，比CAD功能、機器視覺功能、軟件高級編程等，利用FPGA+DSP / ARM + DSP芯片的功能實現高精度的運動控制 (多軸直線、圓弧插補等，運動跟隨，PWM控制等)。
5、運動控制器和運動控制卡的算法幾乎一樣，它們之間的主要區別在于運動控制卡需要依賴于P編程，而運動控制器可以直接寫程序并下載，這樣就可以脫機運行
6、隨著機器視覺的廣泛應用，運動控制與機器視覺得到了良好的結合，相比之下，視覺項目采用運動控制卡能夠節約很大的硬件成本，總而言之，PLC相對來說更偏向于邏輯控制，而弱化于運動控制，而運動控制卡、運動控制器更偏向于運動控制，而弱化于邏輯控制，同時，運動控制卡和運動控制器對開發人員的門檻也要相對高一些，因此大家可以根據自己的實際情況，選擇合適的解決方案。

GDD471A001

GDD471A001 ABB control card module
First of all, to be clear, whether it is PLC, or motion controller, motion control card, their essence is a controller, mainly responsible for the control of the motion axis in the automation system, but also support the control of input and output signals. From the perspective of difference, there are mainly the following points:
1, GDD471A001 ABB control card module PLC expertise lies in logic 10 control, to achieve some complex logic control is very easy. For motion control, the general low-end PLC is mainly through the high-speed output point to pulse control, and the high-end PLC is generally controlled by the bus, the commonly used bus includes Profinet, EtherCAT, CC-Link and so on.
2, GDD471A001 ABB control card module Motion control card through the PCI slot the control card is inserted in the PC host, can also be connected to the PC host through a large network; Using high-level programming languages C++, C#, VB, http:/VBNETlabview and other programming languages for development; The control card AP interface function provided by the motion control card manufacturer is used in programming to realize the use of control card resources. Motion control cards are also divided into pulse type and bus type, and the general bus type is slightly more expensive than the pulse type.
3, GDD471A001 ABB control card module PLC has the advantages of reliable work, simple programming, but its motion control function is relatively simple, PLC application process mainly through PLC+HMI, which leads to a certain limitation of the visual interface, so now based on PLC PC applications are more and more widely;
Motion control card can use the powerful functions of PC, than CAD function, machine vision function, software advanced programming, etc., the use of FPGA+DSP/ARM +DSP chip functions to achieve high-precision motion control (multi-axis straight line, arc interpolation, motion following, PWM control, etc.).
5, the motion controller and the motion control card algorithm is almost the same, the main difference between them is that the motion control card needs to rely on P programming, and the motion controller can directly write programs and download, so that you can run offline
6, with the wide application of machine vision, motion control and machine vision have been a good combination, in contrast, visual projects using motion control card can save a lot of hardware costs, all in all, PLC is relatively more inclined to logic control, and weakened in motion control, and motion control card, motion controller is more inclined to motion control, and weakened in logic control, At the same time, the threshold of motion control cards and motion controllers for developers is also relatively high, so we can choose the right solution according to our actual situation.

GDD471A001
