IC693CPU374是GE發那科90-30系列的可編程邏輯控制器(PLC)模塊。該模塊是一個處理器模塊，用于承載用戶程序，通過嵌入式通信端口執行與處理器之間的邏輯和管理數據交換。

IC693CPU374也可以稱為控制器。該控制器內置微處理器，內置586處理器，處理速度為133 MHz。它有一個典型的掃描速率0.15毫秒每1K布爾接觸邏輯。該控制器模塊具有單一槽位寬度，可安裝在90-30 PLC機架上。

IC693CPU374的用戶內存為240KB。它有兩個以太網通信端口，支持10/100 Mbps的傳輸速度，具有自動感應能力。這些端口使控制器能夠連接到以太網網絡，以便與編程工作站(如臺式機或筆記本電腦)通信，與人機界面(HMI)和監控和數據采集(SCADA)系統通信，以及用于消息傳遞功能的其他處理器。本控制器也可以通過標準電源或大容量電源上的RS485通信接口進行通信。

該控制器接受使用各種編程軟件應用程序開發的用戶程序，如VersaPro 2.03或更高版本，simplicity Machine Edition Logic Developer 2.60或更高版本和控制軟件2.50或更高版本。使用已有的用戶程序?qū)刂破鬟M行在線編輯時，請使用相同版本或更高版本的軟件。

IC693CPU374

IC693CPU374 CPU的處理器速度為133兆赫茲，總用戶內存為240 KB。程序存儲器可根據應用程序要求配置，它包括可配置范圍為128至32,640字的寄存器存儲器，以及用于模擬輸入和模擬輸出的可配置存儲器。系統寄存器的內存支持多達28個單詞，用戶可以設置大約2000個計時器和計數器。

IC693CPU374 CPU采用AMD SC520類型的80386EX處理器，它有2個內置以太網端口，允許10/100 base-T/TX通信。特色以太網端口通過RJ-45連接器連接。該單元還支持電源上的RS-485端口，并允許通過SNP和SNPX協議進行通信。除此之外，該單元還支持幾種常用的程序存儲設備。

IC693CPU374

The IC693CPU374 is a programmable logic controller (PLC) module of the GE Fanuc 90-30 series. The module is a processor module for hosting user programs that perform logical and management data exchange with the processor via an embedded communication port.

IC693CPU374 can also be called controller. The controller has a built-in microprocessor with a built-in 586 processor and a processing speed of 133 MHz. It has a typical scan rate of 0.15 ms per 1K Boolean contact logic. The controller module has a single slot width and can be mounted on a 90-30 PLC rack.

The user memory of IC693CPU374 is 240KB. It has two Ethernet communication ports, supports 10/100 Mbps transmission speeds, and has automatic sensing capabilities. These ports enable the controller to connect to an Ethernet network to communicate with programming workstations such as desktop or laptop computers, with human machine interface (HMI) and supervisory control and data acquisition (SCADA) systems, and with other processors for messaging functions. The controller can also communicate via the RS485 communication interface on a standard power supply or a large capacity power supply.

The controller accepts user programs developed using a variety of programming software applications, such as VersaPro 2.03 or later, simplicity Machine Edition Logic Developer 2.60 or later, and Control software 2.50 or later. When using an existing user program to edit the controller online, use the same or later version of the software.

The IC693CPU374 CPU has a processor speed of 133 megahertz and a total user memory of 240 KB. Program memory can be configured according to application requirements, and it includes register memory with a configurable range of 128 to 32,640 words, as well as configurable memory for analog input and analog output. The memory of the system register supports up to 28 words, and users can set about 2,000 timers and counters.

The IC693CPU374 CPU uses an 80386EX processor of the AMD SC520 type, which has 2 built-in Ethernet ports that allow 10/100 base-T/TX communication. Featured Ethernet ports are connected through RJ-45 connectors. The unit also supports an RS-485 port on the power supply and allows communication via SNP and SNPX protocols. In addition, the unit also supports several commonly used program storage devices.

IC693CPU374
