部件號IC695CPE310
外形背板
用戶內存13MB
I/O32k 位離散量 I/O，32k 字模擬量 I/O
能量包隨附
冗余支持介質冗余 (MRP)，帶 PNC001
以太網端口3 – 2 端口開關 10/100/1000
以太網協議SRTP 客戶端/服務器，Modbus TCP/IP，OPC UA，EGD，PROFINET，DNP3 電站，IEC-61850 客戶端，IEC-104 服務器，HART Passthrough
串行協議ASCII 串行協議，Modbus/RTU
遠程 I/O 設備255 單工，帶 PNC001
USB 接口1 個 USB-A 2.0
環境0 至 60℃
機構認證UKCA，UL，cUL，RoHS，CCC，F(xiàn)CC，Reach，UL HazLoc C1D2，ATEX Zone 2
海事認證ABS，BV，LRDNV GL基于標簽的編程等編程工具，可重用代碼庫，可改進在線故障排除的測試編輯模式
用戶友好環境，可提高設計靈活性并提高工程效率和生產率
支持 PROFINET 的設備增加即插即用功能，便于安全地連接機器、數據和人員
高速多核處理器，可提高吞吐量，無任何信息瓶頸
支持高密度離散量 I/O 模塊、通用模擬量模塊（每個通道均可配置 TC、RTD、應變儀、電壓和電流）、隔離模擬量模塊、高密度模擬量模塊、高速計數器和運動模塊

IC695CPE310

孤立的串行端口實現傳感器和儀器之間穩定可靠的集成
IC695CPE310是GE Fanuc PACSystem RX3i系列中的一款CPU。CPU可以對機器、流程和材料處理系統進行實時控制。它通過兩用PCI和串行背板與I/O和智能選項模塊通信。
IC695CPE310擁有1.1 GHz的Atom處理器和10 MB的內存。其嵌入式以太網接口支持10Mb/秒和100 MB/秒的兩種連接。它還具有RS-485和RS-232串行端口。該模塊支持多達512個程序塊，每個程序塊可達128 KB。
IC695CPE310包含Modbus RTU從機、SNP和串行I/O協議，同時使用SNP協議與人機界面(HMI)設備通信。
您可以用梯形圖、結構化文本、C或功能塊圖編程語言對IC695CPE310進行編程。當設備通電時，設備外殼上貼有標簽的led指示燈可以是綠色、紅色、熄滅或閃爍。這將提高故障排除的效率，并讓您可以一目了然地驗證系統狀態。
IC695CPE310可以安裝在主RX3i控制器機架的任何一對插槽中，編號最高的兩個插槽除外。
IC695CPE310中的處理器比C695CPU310中的300 MHz賽揚處理器快大約三倍。您可以從CPU310升級到CPE310，而無需更改原有的PME軟件。請注意，如果您決定從CPU310升級到CPE310，則CPE310上的RS-232端口不會在引腳5上提供5V電源。

IC695CPE310

Part number IC695CPE310
Contour backplane
User memory 13MB
I/O32k bit discrete I/O, 32k word analog I/O
Energy packs are included
Redundancy Supports media redundancy (MRP) with PNC001
Ethernet port 3-2 Port switch 10/100/1000
Ethernet Protocol SRTP client/server, Modbus TCP/IP, OPC UA, EGD, PROFINET, DNP3 power Station, IEC-61850 client, IEC-104 server, HART Passthrough
Serial Protocol ASCII Serial protocol, Modbus/RTU
Remote I/O device 255 simplex with PNC001
USB port One USB-A 2.0
Environment 0 to 60℃
Agency certification UKCA, UL, cUL, RoHS, CCC, FCC, Reach, UL HazLoc C1D2, ATEX Zone 2
Maritime Certification ABS, BV, LRDNV GL Tag based programming and other programming tools, reusable code base, improve test editing mode for online troubleshooting
User-friendly environment for increased design flexibility and improved engineering efficiency and productivity
Profinet-enabled devices add plug-and-play capabilities to securely connect machines, data, and people
High speed multi-core processor for increased throughput without any information bottlenecks
Supports high-density discrete I/O modules, universal analog modules (TC, RTD, strain gauge, voltage and current can be configured per channel), isolated analog modules, high-density analog modules, high-speed counters and motion modules
Isolated serial ports enable stable and reliable integration between sensors and instruments
The IC695CPE310 is a CPU in the GE Fanuc PACSystem RX3i family. The CPU provides real-time control of machines, processes, and material handling systems. It communicates with the I/O and Smart Options modules via dual-purpose PCI and serial backplanes.
The IC695CPE310 has a 1.1GHz Atom processor and 10 MB of RAM. Its embedded Ethernet interface supports both 10Mb/ s and 100MB/s connections. It also has RS-485 and RS-232 serial ports. The module supports up to 512 blocks of 128 KB each.
The IC695CPE310 contains the Modbus RTU slave, SNP, and serial I/O protocols, while using the SNP protocol to communicate with human machine interface (HMI) devices.
You can program the IC695CPE310 in ladder diagram, structured text, C, or function Block diagram programming languages. When the device is powered on, the labeled led indicator on the device housing can be green, red, off, or blinking. This increases the efficiency of troubleshooting and allows you to verify system status at a glance.
The IC695CPE310 can be installed in any pair of slots in the main RX3i controller rack, except for the two highest-numbered slots.
The processor in the IC695CPE310 is about three times faster than the 300 MHz Ceon processor in the C695CPU310. You can upgrade from CPU310 to CPE310 without changing your original PME software. Note that if you decide to upgrade from CPU310 to CPE310, the RS-232 port on the CPE310 will not provide 5V power on pin 5.

IC695CPE310
