IC754VSF12CTD是GE發那科智能平臺在其操作接口產品線下制造和設計的快速面板控制和視圖。GE發那科IC754VSF12CTD快速面板控制和視圖有一個平板顯示器，每像素16位，總共65,536種顏色。它有一個12英寸的屏幕，并使用一個特殊的機制來提供一個明亮的界面屏幕。顯示器支持800 × 600像素的分辨率;這種觸摸屏允許用戶與他們的設備和機器交互，同時允許他們監控任何進程和進展。GE Fanuc IC754VSF12CTD快速面板控制和視圖必須安裝在具有與NEMA額定面板或外殼相當特性的平面上。建議留出至少3英寸的額外空間，以提供足夠的通風;如果設備放置在室外，應避免陽光直射。
IC754VSF12CTD
重要的是，這個模塊的工作溫度不超過環境空氣溫度。GE Fanuc IC754VSF12CTD快速面板控制和視圖具有觸摸屏，鍵盤，通信端口，CF端口，USB端口，以太網，擴展總線，dip開關和閃存。這個界面在Windows上運行;CPU采用XScale處理器，該模塊具有64 MB的閃存，并具有內存擴展插槽。GE Fanuc IC754VSF12CTD快速面板控制和視圖在24伏直流輸入電壓下工作，實際功率為48瓦，重量約為5.2磅(2.36公斤)。
IC754VSF12CTD
The IC754VSF12CTD is a fast panel control and view for GE Fanuc’s intelligent platform manufactured and designed under its operational interface products. The GE Fanuc IC754VSF12CTD Fast Panel Control and View has a flat panel display with 16 bits per pixel for a total of 65,536 colors. It has a 12-inch screen and uses a special mechanism to provide a bright interface screen. The display supports a resolution of 800 × 600 pixels; This touchscreen allows users to interact with their devices and machines while allowing them to monitor any processes and progress. GE Fanuc IC754VSF12CTD Quick Panel controls and views must be mounted on a flat surface with characteristics comparable to those of the NEMA rated panel or housing. It is recommended to allow at least 3 inches of extra space to provide adequate ventilation; If the device is placed outdoors, avoid direct sunlight.
It is important that the operating temperature of this module does not exceed ambient air temperature. GE Fanuc IC754VSF12CTD Fast panel control and view featuring touch screen, keyboard, communication port, CF port, USB port, Ethernet, expansion bus, dip switch and flash memory. This interface runs on Windows; The CPU is powered by an XScale processor, and the module has 64 MB of flash memory with a memory expansion slot. The GE Fanuc IC754VSF12CTD fast panel control and view operates at 24 volts DC input voltage with an actual power of 48 watts and a weight of approximately 5.2 pounds (2.36 kg).
IC754VSF12CTD
