IC754VSI12CTD是通用電氣(GE)發那科自動化制造的操作員面板。這個操作面板是QuickPanel人機界面(HMI)設備的一部分。該HMI設備預裝了Microsoft Windows Compact Embedded (CE)操作系統，該操作系統提供了任何操作員或用戶都熟悉的配置和維護界面。它不僅提供了一個用戶友好的環境，它還提供了標準的微軟Windows命令和功能，如文件傳輸協議，袖珍Internet Explorer，遠程訪問和遠程瀏覽，PDF查看器和其他命令。

IC754VSI12CTD允許任何操作員或用戶通過提供的監視器，觸摸輸入接口和通信接口監視或控制連接的機器或過程。為了監控該系統，所提供的12英寸彩色薄膜晶體管(TFT)顯示屏能夠通過定制設計的模擬提供該過程的可視化。此外，彩色顯示屏幕支持實現彩色編碼的動畫和狀態顯示，以增加信息級別。控制命令是通過觸摸屏輸入的，它允許操作員通過觸摸適當?shù)倪\(yùn)行時圖標或?qū)ο笾苯虞斎朊?。與控制器的通信使用單個RS232 / RS485組合端口在點對點或多滴串行拓?fù)渲型瓿?，而網絡和多節點通信通過支持傳輸速率為10/100 Mbps的以太網通信接口完成。

IC754VSI12CTD

IC754VSI12CTD由24VDC外部電壓電源供電，功耗小于48W。當與Proficy Machine Edition 5.0或更高版本一起使用時，此操作面板支持歷史數據記錄，視圖和Visual Basic。

通用電氣的IC754VSI12CTD終端是輕量級的，被設計為現代接口機QuickPanel組的一部分。IC754VSI12CTD終端使客戶能夠通過RS-232/RS-485通信端口和相關的HMI-CAB-C110通信鏈路，使用Proficy View (Machine Edition)編程軟件與他們的機器進行接口。用戶可以通過觸摸屏輸入數據和信息。

IC754VSI12CTD由12伏或24伏直流電壓控制。它的全部內存為32mb，運輸重量和尺寸分別為10磅和16 x 14 x 8英寸。該裝置有多種設計，以適應不同客戶的需要。它是任何有組織的家庭網絡的完美選擇，但它也可以作為一個單獨的單位在工廠中使用。IC754VSI12CTD是加工車間人機界面應用的完美解決方案。不同的亮點，特別是IC754VSI12CTD結合了一個進步的XScale芯片，該芯片將高分辨率觸摸屏管理界面與各種I/O選擇結合在一起。還有各種各樣的標準端口和開發傳輸，它們與大多數硬件部件和幾種類型的內存兼容，甚至可以滿足市場上最苛刻的應用程序。

這個QuickPanel終端是由微軟Windows CE操作系統驅動的，它可以為應用程序的發展提供最優化的計劃。如果突然發生電源故障，客戶端信息可以保存在SRAM中，SRAM由電池完全備份。固件的更新可以從手冊中描述的支持站點下載。這是制造商提供的。

IC754VSI12CTD

The IC754VSI12CTD is an operator panel manufactured by General Electric (GE) Fanuc Automation. This operation panel is part of the QuickPanel Human Machine Interface (HMI) device. The HMI device comes preloaded with the Microsoft Windows Compact Embedded (CE) operating system, which provides a configuration and maintenance interface familiar to any operator or user. Not only does it provide a user-friendly environment, it also provides standard Microsoft Windows commands and features such as File Transfer Protocol, Pocket Internet Explorer, Remote Access and Remote Browsing, PDF viewer, and other commands.

The IC754VSI12CTD allows any operator or user to monitor or control the connected machine or process through the provided monitor, touch input interface and communication interface. To monitor the system, the supplied 12-inch color thin-film transistor (TFT) display provides visualization of the process through custom-designed simulations. In addition, the color display screen supports color-coded animations and status displays to increase the level of information. Control commands are entered via a touch screen, which allows the operator to enter commands directly by touching the appropriate runtime icon or object. Communication with the controller is done in a point-to-point or multi-drop serial topology using a single RS232 / RS485 combination port, while network and multi-node communication is done via an Ethernet communication interface that supports transfer rates of 10/100 Mbps.

The IC754VSI12CTD is powered by a 24VDC external voltage supply and consumes less than 48W. When used with Proficy Machine Edition 5.0 or later, this action panel supports historical data logging, views, and Visual Basic.

Ge’s IC754VSI12CTD terminal is lightweight and designed as part of the QuickPanel group of modern interface machines. The IC754VSI12CTD terminal enables customers to interface with their machines using Proficy View (Machine Edition) programming software via the RS-232/RS-485 communication port and the associated HMI-CAB-C110 communication link. Users can enter data and information through the touch screen.

The IC754VSI12CTD is controlled by 12 V or 24 V DC voltage. It has 32mb of total memory, shipping weight and dimensions of 10 pounds and 16 x 14 x 8 inches, respectively. The unit is available in a variety of designs to suit the needs of different customers. It is perfect for any organized home network, but it can also be used as a separate unit in a factory. The IC754VSI12CTD is the perfect solution for human-machine interface applications in the machining shop. Different highlights, in particular the IC754VSI12CTD combines an advanced XScale chip that combines a high-resolution touchscreen management interface with a variety of I/O options. There is also a wide variety of standard ports and development transfers that are compatible with most hardware components and several types of memory to meet even the most demanding applications on the market.

This QuickPanel terminal is powered by the Microsoft Windows CE operating system, which provides optimal planning for application development. In the event of a sudden power failure, client information can be saved in SRAM, which is fully backed up by the battery. Firmware updates can be downloaded from the support site described in the manual. This is provided by the manufacturer.
