The IS200VCMIH2BEE was designed by General Electric as part of its Speedtronic Mark VI industrial gas and steam turbine control system. This version of the Speedtronic system is commonly used in processing plants and power generation applications to control the speed of the turbine during start-up, synchronize the generator, provide turbine load control, and prevent load loss and turbine overspeed situations.
The IS200VCMIH2BEE is part of the Unit Data Highway (UDH). It acts as the main communication controller board. Data is read and transmitted to other boards via Fiber Optic Ethernet (IONet).
VCMI boards can be designed for simplex or TMR(three-mode redundancy) applications. The simplex board will have one IONet port, while the TMR board will have three. The IS200VCMIH2BEE board is a TMR board.
IS200VCMIH2BEE uses SIFT voting (software for fault tolerance). The data is broadcast as a packet to all remote racks. The VCMI board at these remote locations extracts the appropriate packet data.
The IS200VCMIH2BEE board has two panels. The back of the circuit board is mainly equipped with resistors and capacitors. The front of the board is more complex and includes connector ports (including two backplanes), inductors/chokes, tp test points, and integrated circuits. The additional front panel has three IONet ports as well as a single male serial port. It has a reset button, two setting screws, four sets of LED indicators (one set of 3, one set of 6, one set of 8, another set of 3) and the company logo and board number are also marked on the panel.
IS200VCMIH2BEE
