IS200VCRCH1B是GE Mark VI板組件。MKVI是燃?xì)夂驼羝啓C(jī)管理系統的Speedtronic家族的一部分，該家族自20世紀60年代發布Mark I以來一直由通用電氣開發和改進。MKVI是Speedtronic生產線上的第五個管理系統，具有對所有保護參數和關鍵控制的三重冗余控制，以及用于保護和監測渦輪系統的先進控制機制。
IS200VCRCH1B作為分立輸入/輸出板。這是一個單槽板，具有與VCCC板相同的功能，但不包括子板，因此占用較少的機架空間。但是，由于該板的繼電器輸出使用VME機架上的J3/J4端口，因此必須在前面板上放置電纜。如果不希望這樣，請使用VCCC板而不是VCRC PCB。
IS200VCRCH1B
IS200VCRCH1B有一個帶有兩個電纜連接器的前面板(J33和J44)。面板上還裝有三個LED組件，它們被放置在面板的上角附近。這些led有綠色、紅色和橙色，分別標有運行、故障和狀態。
IS200VCRCH1B的表面填充了兩個背板連接器。幾個導電連接器位于電路板表面(P4到P6)。該板還包括電阻、二極管、電容器和TP測試點。這塊電路板有30多個晶體管和兩個電源。位于電路板表面的集成電路包括fpga和各種SRAM和RAM芯片。有關IS200VCRCH1B的更多信息可以使用數據表，手冊或Mark VI控制系統指南找到。
IS200VCRCH1B
The IS200VCRCH1B is a GE Mark VI board component. The MKVI is part of the Speedtronic family of gas and steam turbine management systems, which has been developed and improved by GE since the release of the Mark I in the 1960s. The MKVI is the fifth management system on the Speedtronic production line, featuring triple redundant control over all protection parameters and critical controls, as well as advanced control mechanisms for protecting and monitoring turbine systems.
The IS200VCRCH1B serves as a discrete input/output board. This is a single slot board that has the same functionality as the VCCC board, but does not include a sub-board, so it takes up less rack space. However, since the relay output of this board uses J3/J4 ports on the VME rack, cables must be placed on the front panel. If you do not want this, use a VCCC board instead of a VCRC PCB.
The IS200VCRCH1B has a front panel with two cable connectors (J33 and J44). The panel is also equipped with three LED components, which are placed near the top corner of the panel. These leds come in green, red and orange and are marked with operating, fault and status respectively.
The surface of the IS200VCRCH1B is filled with two backplane connectors. Several conductive connectors are located on the board surface (P4 to P6). The board also includes a resistor, diode, capacitor, and TP test point. The board has more than 30 transistors and two power supplies. Integrated circuits located on the surface of the board include FPgas and various SRAM and RAM chips. More information about the IS200VCRCH1B can be found using data sheets, manuals or the Mark VI Control System Guide.
IS200VCRCH1B
