IS215UCVEH2AE是通用電氣Mark VI Speedtronic控制系統的一個組件。該單板作為VME控制卡。VME卡機架是Mark VI的標準機架，可作為13或21槽機架。
IS215UCVEH2AE是一種矩形板，帶有附加的前面板。面板在頂部和底部有一個固定螺釘，以幫助將電路板安裝到機架系統中后固定到位。前面板包括1個以太網接口、2個COM接口和1個LAN接口。它也有一個夾層卡的空缺。
該板本身包括板體內的垂直引腳連接器和沿板邊緣的直角引腳連接器。此外，電路板有幾個集成電路，電阻器，電容器，扼流圈和其他組件。此外，還有一個小電路板安裝在一個角度在板的中心和散熱罩位于一半以上的板。
IS215UCVEH2AE
IS215UCVEH2A由通用電氣制造，是一款雙面控制器板，設計為該公司Mark VI Speedtronic系統的一部分。 MK VI是GE有史以來發布的最先進的Speedtronic系統之一，使用戶能夠設置TMR或simplex系統，用于燃?xì)夂驼羝I(yè)渦輪機控制。IS215UCVEH2A包括一個前面板，該面板內置三個位于電路板頂部的 LED 指示燈。這些是狀態指示器。此外，面板還包括一個復位按鈕、一個用于夾層卡的開口、額外的 LED 以及用于 LAN、SVGA、以太網和其他連接的端口。面板標有GE徽標和電路板ID (與連接的電路板一樣)，并包括兩個固定螺釘，有助于在機架插入后將電路板固定到位。通常，此主板放置在第二個插槽中。
IS215UCVEH2AE
The IS215UCVEH2AE is a component of the General Electric Mark VI Speedtronic control system. The board functions as a VME control card. The VME card rack is the standard rack for Mark VI and can be used as a 13 or 21 slot rack.
The IS215UCVEH2AE is a rectangular board with an additional front panel. The panel has a set screw at the top and bottom to help secure the board in place after it is installed into the rack system. The front panel provides one Ethernet port, two COM ports, and one LAN port. It also has a mezzanine card vacancy.
The board itself includes a vertical pin connector inside the board and a right Angle pin connector along the edge of the board. In addition, the board has several integrated circuits, resistors, capacitors, chokes and other components. In addition, there is a small circuit board mounted at an Angle in the center of the board and a heat sink located more than half of the board.
Manufactured by General Electric, the IS215UCVEH2A is a double-sided controller board designed as part of the company’s Mark VI Speedtronic system. The MK VI is one of the most advanced Speedtronic systems ever released by GE, enabling users to set up TMR or simplex systems for gas and steam industrial turbine control. The IS215UCVEH2A includes a front panel with three built-in LED indicators located on top of the board. These are status indicators. In addition, the panel includes a reset button, an opening for the sandwich card, additional leds, and ports for LAN, SVGA, Ethernet, and other connections. The panel is marked with the GE logo and board ID (as with the attached board) and includes two setting screws that help hold the board in place once the rack is inserted. Typically, this motherboard is placed in the second slot.
IS215UCVEH2AE
