IS215UCVGH1A是GE為Mark VI系統創建的面板板組件。MKVI是通用電氣發布的蒸汽和燃氣輪機管理系統，是Speedtronic生產線的一部分。Speedtronic系列始于1969年，一直持續到20世紀90年代Mark VI/Mark VIe的發布。

MKVI有五個版本的UCV控制器。IS215UCVGH1A是該控制器的單槽版本。以前的任何控制器都可以直接由IS215UCVGH1A代替。如果更換舊版本的控制器，則不需要升級背板。IS215UCVGH1A安裝在VME機架中。

IS215UCVGH1A

IS215UCVGH1A采用英特爾的超低壓賽揚650處理器芯片。該芯片具有128MB的SDRAM和128MB的閃存。這塊板有一個前面板。面板上有一個復位開關，后面跟著一個SVGA監視器端口。有一個鍵盤/鼠標端口和兩個COM端口(并排，標記為1和2)。單板上有兩個以太網端口堆疊在一起。它們被標記為LAN1和LAN2。有兩個獨立的USB連接器，四個LED指示燈和一個面板開口。

IS215UCVGH1A單板由多個輔助板組成。在一些地方，如果添加了輔助設備，就可以接受它們。單板只有一個背板。電路板表面有電容器、電感線圈、晶體振蕩器、振蕩芯片、跳線開關和集成電路。

IS215UCVGH1A

The IS215UCVGH1A is a panel component created by GE for the Mark VI system. MKVI is a steam and gas turbine management system released by General Electric as part of the Speedtronic product line. The Speedtronic series began in 1969 and continued until the release of Mark VI/Mark VIe in the 1990s.

The MKVI has five versions of the UCV controller. The IS215UCVGH1A is the single-slot version of the controller. Any previous controller can be directly replaced by the IS215UCVGH1A. If a controller of an earlier version is replaced, you do not need to upgrade the backplane. IS215UCVGH1A is installed in the VME rack.

The IS215UCVGH1A uses Intel’s ultra-low voltage Celeron 650 processor chip. The chip has 128MB of SDRAM and 128MB of flash memory. This board has a front panel. There is a reset switch on the panel followed by an SVGA monitor port. There is a keyboard/mouse port and two COM ports (side by side, labeled 1 and 2). Two Ethernet ports are stacked on a board. They are labeled LAN1 and LAN2. There are two separate USB connectors, four LED indicators and a panel opening.

The IS215UCVGH1A board consists of multiple auxiliary boards. In some places, assistive devices are acceptable if they are added. A board has only one backplane. On the surface of the circuit board are capacitors, inductors, crystal oscillators, oscillating chips, jumper switches and integrated circuits.
